Chapter 25 IP Source Guard

GS2200-8/24 User’s Guide

210

25.9.2 ARP Inspection VLAN Configure

Use this screen to enable ARP inspection on each VLAN and to specify when the Switch generates

log messages for receiving ARP packets from each VLAN. To open this screen, click Advanced

Application > IP Source Guard > ARP Inspection > Configure > VLAN.

Figure 131 ARP Inspection VLAN Configure

The following table describes the labels in this screen.

Apply Click Apply to save your changes to the Switch’s run-time memory. The Switch loses

these changes if it is turned off or loses power, so use the Save link on the top

navigation panel to save your changes to the non-volatile memory when you are done

configuring.

Cancel Click this to reset the values in this screen to their last-saved values.

Table 77 ARP Inspection Port Configure (continued)

LABEL DESCRIPTION

Table 78 ARP Inspection VLAN Configure

LABEL DESCRIPTION

VLAN Use this section to specify the VLANs you want to manage in the section below.

Start VID Enter the lowest VLAN ID you want to manage in the section below.

End VID Enter the highest VLAN ID you want to manage in the section below.

Apply Click this to display the specified range of VLANs in the section below.

VID This field displays the VLAN ID of each VLAN in the range specified above. If you

configure the * VLAN, the settings are applied to all VLANs.

Enabled Select Yes to enable ARP inspection on the VLAN. Select No to disable ARP inspection on

the VLAN.
