Chapter 27 Layer 2 Protocol Tunneling

GS2200-8/24 User’s Guide

221

27.2 Configuring Layer 2 Protocol Tunneling

Click Advanced Application > Layer 2 Protocol Tunneling in the navigation panel to display the

screen as shown.

Figure 141 Advanced Application > Layer 2 Protocol Tunneling

The following table describes the labels in this screen.

Table 80 Advanced Application > Layer 2 Protocol Tunneling

LABEL DESCRIPTION

Active Select this to enable layer 2 protocol tunneling on the Switch.

Destination

MAC Address

Specify a MAC address with which the Switch uses to encapsulate the layer 2 protocol

packets by replacing the destination MAC address in the packets.

Note: The MAC address can be either a unicast MAC address or multicast MAC address. If

you use a unicast MAC address, make sure the MAC address does not exist in the

address table of a switch on the service provider’s network.

Note: All the edge switches in the service provider’s network should be set to use the same

MAC address for encapsulation.

Port This field displays the port number.

* Use this row to make the setting the same for all ports. Use this row first and then make

adjustments on a port-by-port basis.

Note: Changes in this row are copied to all the ports as soon as you make them.
