Chapter 28 PPPoE

GS2200-8/24 User’s Guide

228

The following table describes the labels in this screen.

28.3.2 PPPoE IA Per-Port Per-VLAN

Use this screen to configure PPPoE IA settings that apply to a specific VLAN on a port.

Table 87 Advanced Application > PPPoE > Intermediate Agent > Port

LABEL DESCRIPTION

Port This field displays the port number.

* Use this row to make the setting the same for all ports. Use this row first and then make

adjustments on a port-by-port basis.

Note: Changes in this row are copied to all the ports as soon as you make them.

Server Trusted

State

Select whether this port is a trusted port (Trusted) or an untrusted port (Untrusted).

Trusted ports are uplink ports connected to PPPoE servers.

• If a PADO (PPPoE Active Discovery Offer), PADS (PPPoE Active Discovery Session-

confirmation), or PADT (PPPoE Active Discovery Terminate) packet is sent from a PPPoE

server and received on a trusted port, the Switch forwards it to all other ports.

• If a PADI or PADR packet is sent from a PPPoE client but received on a trusted port, the

Switch forwards it to other trusted port(s).

Untrusted ports are downlink ports connected to subscribers.

• If a PADI, PADR, or PADT packet is sent from a PPPoE client and received on an

untrusted port, the Switch adds a vendor-specific tag to the packet and then forwards it

to the trusted port(s).

• The Switch discards PADO and PADS packets which are sent from a PPPoE server but

received on an untrusted port.

Circuit-id Enter a string of up to 63 ASCII characters that the Switch adds into the Agent Circuit ID

sub-option for PPPoE discovery packets received on this port. Spaces are allowed.

The Circuit ID you configure for a specific VLAN on a port (in the Advanced Application >

PPPoE > Intermediate Agent > Port > VLAN screen) has the highest priority.

Remote-id Enter a string of up to 63 ASCII characters that the Switch adds into the Agent Remote ID

sub-option for PPPoE discovery packets received on this port. Spaces are allowed.

If you do not specify a string here or in the Remote-id field for a VLAN on a port, the

Switch automatically uses the PPPoE client’s MAC address.

The Remote ID you configure for a specific VLAN on a port (in the Advanced Application >

PPPoE > Intermediate Agent > Port > VLAN screen) has the highest priority.

Apply Click Apply to save your changes to the Switch’s run-time memory. The Switch loses these

changes if it is turned off or loses power, so use the Save link on the top navigation panel to

save your changes to the non-volatile memory when you are done configuring.

Cancel Click Cancel to begin configuring this screen afresh.
