Chapter 7 System Status and Port Statistics

GS2200-8/24 User’s Guide

7.2.1 Status: Port Details

Click a number in the Port column in the Status screen to display individual port statistics. Use this

screen to check status and detailed performance data about an individual port on the Switch.

Figure 40 Status > Port Details

The following table describes the labels in this screen.

Table 8 Status: Port Details

LABEL DESCRIPTION

Port Info

Port NO. This field displays the port number you are viewing.

Name This field displays the name of the port.

Link This field displays the speed (either 100M for 100Mbps or 1000M for 1000Mbps) and the

duplex (F for full duplex or H for half duplex). It also shows the cable type (Copper or Fiber).
