Chapter 9 VLAN

GS2200-8/24 User’s Guide

9.4 Configure VLAN Port Settings

Use the VLAN Port Setting screen to configure the static VLAN (IEEE 802.1Q) settings on a port.

Click the VLAN Port Setting link in the VLAN Status screen.

Figure 54 Advanced Application > VLAN > VLAN Port Setting

The following table describes the labels in this screen.

Table 20 Advanced Application > VLAN > VLAN Port Setting

LABEL DESCRIPTION

GVRP GVRP (GARP VLAN Registration Protocol) is a registration protocol that defines a way for

switches to register necessary VLAN members on ports across the network.

Select this check box to permit VLAN groups beyond the local Switch.

Ingress Check If this check box is selected, the Switch discards incoming frames on a port for VLANs

that do not include this port in its member set.

Clear this check box to disable ingress filtering.

Port This field displays the port number.

* Settings in this row apply to all ports.

Use this row only if you want to make some settings the same for all ports. Use this row

first to set the common settings and then make adjustments on a port-by-port basis.

Note: Changes in this row are copied to all the ports as soon as you make them.
