13
ENGLISH
ROBOT VACUUM CLEANER CF-3206
The CF-3206 Robot Vacuum Cleaner is an innovative
approach to cleaning. The robot vacuum cleaner is
equipped with a fundamentally new spatialization system,
which allows to build a detailed map of your room and take
into account the peculiarities of the interior layout. The
laser rangefinder installed in the appliance module rotates
in a horizontal plane with a 360 degree view and allows the
appliance to receive updated data on obstacles.
DESCRIPTION
1.
Return home « » / Wi-Fi connection mode button
2.
«Start / Pause» button « », turn on / off the robot
3.
Front bumper
4.
Upper lid
5.
Optical drop protection sensors
6.
Side brushes (R, L)
7.
Contact points for battery charging
8.
Front wheel
9.
Battery compartment lid
10.
Driving wheels
11.
Fixing frame
12.
Central brush assembly
13.
Water tank assembly (with dust bin)
14.
Floor wet cleaning attachment
15.
Laser rangefinder
16.
Water tank eject button
17.
Speaker
18.
«Reset» button
19.
Front panel of photodetectors
20.
Air outlet grid
21.
Dust bin
22.
Dust bin lid
23.
HEPA filter
24.
Primary (pre) filter
Self-cleaning station
25.
Dust chamber lid
26.
Self-cleaning station operation indicator
27.
Infrared emitter window
28.
Charging contacts
29.
Dust intake inlets of the automatic dust collector
30.
Cord storage
31.
Outlet HEPA filter
32.
Outlet filter grid
33.
Dust bag holder
34.
Dust chamber inlet filter
Remote control
35.
Display
36.
Planning mode button « »
37.
Return home button « »
38.
Navigation buttons (vacuum cleaner movement
control)
- forward
- left turn
- right turn
- backward
39.
«Start / Pause» button « »
40.
Suction control button « »
41.
Scheduled cleaning setup button « »
42.
«Along the wall» cleaning mode button « »
43.
Water supply control button « »
44.
Spot/local cleaning button « »
45.
Clock setting button « »
46.
Cleaning brush
47.
Microfiber wet cleaning cloth
48.
Dust bag
SAFETY MEASURES AND OPERATION
RECOMMENDATIONS
Read this instruction manual carefully before using the
robot vacuum cleaner and keep it for the entire operation
period. Mishandling the appliance can cause it to break,
harm the user or damage the property.
To avoid fire, electric shock, and to prevent injury, follow
the guidelines below.
•
Use the appliance in strict accordance with the instruc-
tion manual.
•
Use only the accessories provided with the appliance.
•
Before charging the rechargeable battery for the
first time, make sure that voltage of the mains corre-
sponds to the operating voltage of the self-cleaning
station.
•
Do not charge the rechargeable battery in places with
high humidity and high temperature. Charge the accu-
mulator battery at the temperature from +5° C to +35° C
and relative humidity no more than 80%.
•
When the robot remains idle for a long time, please turn
it off and remove the battery to avoid damage caused by
over-discharging the battery.
•
If the battery compartment lid is deformed, the battery
case is found to be deformed, the battery is swollen
and/or the electrolyte is leaking, do not charge or put
the battery into the appliance to avoid danger.
•
If electrolyte comes into contact with skin or clothing,
rinse immediately with clean water. If ignored, it may
cause skin inflammation or other symptoms.
•
Do not disassemble the battery as this may damage the
battery case and leak electrolyte, which may result in a
serious risk of fire and explosion.
•
If you are not using the self-cleaning station for a long
period of time, unplug the power cord from the electri-
cal outlet.
•
Do not touch the power cord of the self-cleaning station
with wet hands.
•
Do not bend the power cord too much or place heavy
objects on it, otherwise the power cord may be dam-
aged, resulting in a fire or electric shock.
•
Do not subject the battery to strong shocks or drops, as
this may cause leakage, heating or cracking.
•
Do not use non-rechargeable batteries.
•
Do not use the vacuum cleaner outdoors, and on wet
and damp surfaces.
•
Do not use the vacuum cleaner in rooms with unsteady
furniture, especially if there are fragile interior objects or
burning candles placed on it.
•
Do not place or install foreign objects on the vacuum
cleaner body, make sure that there are no pets on the
vacuum cleaner body.
•
Do not switch the appliance on if the air inlet is blocked
by a foreign object.
•
Keep hair, free hanging clothes and interior objects
away from the vacuum cleaner path of motion.
•
Set additional obstacles for the vacuum cleaner when
cleaning the stair landings.
•
Do not use the vacuum cleaner for collecting such
inflammable liquids as gasoline or solvents. Do not
use the vacuum cleaner in places where such liquids
are stored.
