22 RU

аккумуляторная сабельная пила PRCS 10-20V

Список запчастей

NO. SPARE PART NO. SPARE PART

1 Saw blade 34 Big gear

2 Protective floor 35 Reciprocating rod positioning seat

3 Protective orbit 36 Pan head screw with cross groove M4 x 6

4 Flat head semi-hollow rivet Ø6 x 8mm 37 Cover plate

5 Circlip for shaft Ø16mm 38 Straight pin

6 Clamping sleeve 39 Gear shaft sleeve

7 Tool bar fixing sleeve 40 Cover plate

8 Tool rod pin 41 Hexagonal nut M4

9 Steel ball Ø5mm 42 Pan head screw with cross groove M4 x 12

10 Tool rod torsion spring 43 Reset the shell

11 Clamping sleeve 44 Axle sleeve

12 Cutter bar 45 Alignment pin

13 Block felt 46 Reciprocating bar ram

14 Sleeve 47 Deep groove ball bearing

15 Impact cutter bar 48 The motor gear

16 Track lock knob 49 Circlip for shaft Ø12mm

17 Track lock knob insert 50 Circlip for hole

18 Hexagon socket cap screw M4 x 6 51 Pan head screw with cross groove M4 x 8

19 Washer 52 Spring washers Ø4

20 Gear box body 53 Bracket for motor

21 Rail clips 54 Motor

22 Track clamp reset spring 55 Switch

23 Track platen positioning screw 56 Safety switch

24 Knife lifting knob 57 Switch safety spring

25 Knife lifting knob spring 58 Housing

26 Circlip for shaft Ø8mm 59 Self-locking push rod

27 Knife lifting knob insert 60 Inductance

28 Oilite bushing Ø12 x Ø8 x 10mm 61 Dual battery pack components

29 The big gear shaft 62 Charger

30 Circlip for shaft Ø8mm 63 Cross groove pan head self tapping screw

ST4.2 x 13

31 Deep groove ball bearing 64 Fuselage insert bracket

32 Circlip for hole 65 Positive pole of motor conductor

33 Washer
