SPECIFICATIONS

GENERAL SPECIFICATIONS

Description: Dremel Glue Gun

Model number 910 920 930 940

Glue

temperature

• low (LO) - 105°C 105°C -

• high (HI) 165°C - 165°C 195°C

Glue stick Ø 7 mm 7 mm 7 mm 11/12 mm

Protection

Class

/II /II /II /II

EXTENSION CORDS

Use completely unrolled and safe extension

cords with a capacity of at least 5 Amps.

ASSEMBLY

GENERAL

The glue gun is intended for the quick gluing of

clean, dry and grease-free materials with glue

heated to its melting point.

PICTURE 1a/1b

1. Nozzle

2. Glue stick

3. Feed trigger

4. Stand

5. Temperature switch

PICTURE 1c

6. On/off switch with indicator light

7. Detachable cord

8. Stand release button

9. Exchangeable nozzle

USE

SWITCHING ON/OFF

SWITCHING ON:

Plug Dremel Glue Gun into a standard 230 V

electrical outlet.

Models 910, 920 and 930:

• Once the glue gun is plugged in, it is on

and heating.

Dual Temperature Glue Gun Model 930:

• Adjust switch (5) to low or high temperature

setting to turn the Glue Gun on. Consult

with glue stick package to determine

appropriate temperature.

Model 940:

• Connect the power cord to the glue gun.

• Switch the glue gun on with the main

switch. Indicator light (6) will let you know

the glue gun is on and heating.

SWITCHING OFF:

• Pull the mains plug (models 910, 920 and

930).

• Switch the unit ON/OFF with switch (6;

model 940). Pull the mains plug.

Allow the unit to cool completely before storing.

The hot nozzle can cause damage.

GETTING STARTED

PREPARATIONS FOR GLUING

The surfaces to be glued must be clean, dry

and free of grease. Roughen smooth surfaces

before gluing. DO NOT USE INFLAMMABLE

SOLVENTS FOR CLEANING! The ambient

temperature and the work piece to be glued

must not be colder than +5 °C or warmer than

+50 °C. Warm rapidly cooling materials (e.g.,

steel) for better adhesion.

GLUING

DANGER OF BURNING! The glue and the

nozzle tip (1) become very hot. Do not allow the

nozzle tip or hot glue to come into contact with

persons or animals. If hot glue touches the skin,

immediately hold the spot for some minutes under

a stream of cold water. Do not try to remove the

glue from the skin.

Models 910, 920 and 930:

• Allow glue gun to reach operating

temperature before using (±5mins).

Insert the glue stick (2). Press the feed

trigger (3).

Model 940:

• Once the cord is detached, the glue gun

remains operable for 5mins, before it

needs to heat up.

NOTE: For your rst use, you may need to load

up to two full glue sticks before glue begins

to ow.

• Squeeze trigger (3) to apply glue onto

desired surface.

• Apply parts together.

• Allow glue to cool before handling object or

surface.

TIP: Dremel also supplies glitter and colour

sticks for decorative purposes. These sticks

have been specially developed for creative

projects and low temperature (105 °C).

The colour sticks can also be used for sealing

decorations. To be able to quickly change

colours, it is recommended to cut the sticks into

3 cm pieces before inserting into the Glue Gun.

GLUESTICKS

Glue

Model

910 920 930 940

165°C

105°C

165°C

105°C

195°C

GG01

Multipurpose glue, 7mm

- -

GG02

Multipurpose glue, 7mm

- -

GG03

Woodglue, 7mm

- -

GG04

Glitter glue, 7mm

- -

GG05

Colour glue, 7mm

- -

GG11

Multipurpose glue, 11mm

- - -

GG13

Woodglue, 11mm

- - -

DRIP-CONTROL FUNCTION

When heated up, the glue gun has a

drip-control function. This prevents the glue

from dripping when the glue gun is at operating

temperature.

NOTES: During heating-up the glue gun may

release a few drops of glue.

Do not use glitter or colour sticks at high

temperature. The drip-control function will not

work properly.

Model 940: EXCHANGE NOZZLE

• Use a spanner and turn the nozzle from

the housing.

• Mount a new nozzle on the housing.
