Profactor Armaturen GmbH

Adolf-Kolping-Str. 16, 80336 München, Germany, Telefon: +49 89 21546092

E-mail: info@pf-armaturen.de, Internet: www.profactor.de

All pipe threads are made according to ISO 228-1:2000, DIN EN 10226-2005. Metric threads

made according to ISO 261:1998.

The manifold is made of CW617N brass according to the European standard DIN EN 12165-

2011. Distance between the centers of the outlets — 45 mm.

4. DESCRIPTION

Valves located on each outlet make it possible to isolate any connected consumer direct from

the manifold during installation, maintenance, or replacement operations.

When the knob is rotated clockwise, the valve closes the outlet. Turning the handle

counterclockwise opens the outlet.

Manifolds have nameplates, they are located in the valve handles, each plate has a color

designation — hot/cold water and the name of connected consumer.

Screw

Red/Blue double sided disc

Double sided disc with discriptions

Knob
