4 English

CHANGE OF BATTERIES

Open battery compartment. Insert batteries. Take care to correct polarity.

Close battery compartment. ATTENTION: If you are not going to use instru-

ment for a long time, take out batteries.

OPERATION

Place the line laser on the working surface or mount it on the tripod/pil-

lar or wall mount (comes with the instrument). Switch on the line laser :

turn the compensator switch (3) to the position “ON”. When enabled, the

vertical and horizontal plane projected constantly. Visual alarm (blinking

line) and audible signal indicate that the device was not installed within the

compensation range ± 3 º. To properly work align the unit in a horizontal

plane.

TO CHECK THE ACCURACY OF LINE LASER (SLOPE OF PLANE)

Set up the line laser between two walls, the distance is 5 m.Turn on the

Line Laser and mark the point of cross laser line on the wall. Set up the

instrument 0,5-0,7m away from the wall and make, as described above, the

same masrks. If the dierence {a1-b2} and {b1-b2} is less then the value of

“accuracy” (see spesications), there is no need in calibration.

Example: when you check the accuracy of Line Laser the dierence is

{a1-a2}=5 mm and {b1-b2}=7 mm. The instrument’s error: {b1-b2}-

{a1-a2}=7-5=2 mm. Now you can compare this error with standard error.

If the accuracy of Line Laser isn’t corresponding with claimed accuracy,

contact the authorized service center.

TO CHECK THE ACCURACY OF HORIZONTAL BEAM

Choose a wall and set laser 5M away from the wall. Turn on the laser and

cross laser line is marked A on the wall. Find another point M on the hori-

zontal line, the distance is around 2.5m. Swivel the laser, and another cross
