Line Laser ADA CUBE 3-360 is designed to check the horizontal and vertical

position of the surfaces of the elements of building structures and also

to transfer the angle of inclination of the structural part to similar parts

during construction and installation works.

SPECIFICATIONS

Laser beam .....................................................

Horizontal line 360°/2 vertical lines 360

Light sources ................................................. 3 laser diodes with laser emission

wave length of 638 nm

Laser safety class .......................................... Class 2, <1mW

Accuracy ........................................................... ±3mm/10m

Self-leveling range ......................................... ±4°

Operating range with/without receiver ...... 230/66 ft (70/20 m)

Power source .................................................. Li-ion battery 3.7 V /

3xAA 1,5V

Tripod thread .................................................. 2x1/4”

Operating temperature .............................. -5°C +45°C

Weight ...............................................................1,01 lb (460 g)

*depends on illumination

THE MANUFACTURE RESERVES THE RIGHT TO MAKE CHANGES (NOT

HAVING AN IMPACT ON THE SPECIFICATIONS) TO THE DESIGN,

COMPLETE SET WITHOUT GIVING PRIOR WARNING.

APPLICATION

FUNCTIONAL DESCRIPTION

1. 360

horizontal line and 2 vertical laser lines 360

2. Quick self-leveling: when line accuracy is out of the range the laser

line ashes and the warning sound is produced.

3. Compensator locking system for safe transportation.

4. Intermediate compensator locking system for slope operation.

5. Indoor and outdoor performance function.

English
