BlastRazor Z-100RC/BlastRazor Z-200RC Art.10400101/10400201

2.1 Package

Article Model Description, package

10400101 BlastRazor-100RC Abrasive Blasting Machine, 100 L, screen,

cover, moisture and oil separator lter CAF-

1, remote control unit RCV, remote control

handle DMH, abrasive metering valve FSV,

twin hose in RC TWINLINE 20m, tting set for

RC hose.

10400201 BlastRazor-200RC Abrasive Blasting Machine, 200l, screen,

cover, moisture and oil separator lter CAF-

1, remote control unit RCV, remote control

handle DMH, abrasive metering valve FSV,

RC twin hose TWINLINE 20m, tting set for

RC hose.

10110870 RCV Remote control valve (5, Fig.2.1)

10110880 DMH Remote control handle (11, Fig.2.1)

10112106 TWINLINE Remote control twin hose, d=6mm, roll 40 m

(4, Fig.2.1)

1 — Cover

2 — Screen

3 — Machine tank

4 — RC hose

5 — Remote control unit

6 — Moisture and oil separator

7 — Abrasive blasting hose

8 — Operator helmet

9 — Nozzle holder

10 — Nozzle

11 — RC handle

12 — Breathing air hose

13 — Breath air lter

14 — Safety ball valve
