5

CONTRACOR

®

BlastRazor Z-100, BlastRazor Z-200 Art. 10400100/10400200

Fig. 2.1.

1 — cover

2 — screen

3 — machine tank

4 — pressurizing ball valve

5 — upper air line ball valve

6 — moisture and oil separator

7 — lower air line ball valve

8 — abrasive blasting hose

9 — Operator Helmet

10 — nozzle holder

11 — nozzle

12 — breathing air hose

13 — breathing air lter

Table. 2.1.

Article Model Description, conguration

10400100 BlastRazor

Z-100

Abrasive Blasting Machine, 100 l,

screen,

cover,

lter, oil and moisture separator CAF-3,

abrasive metering valve FSV.

10400200 BlastRazor

Z-200

Abrasive Blasting Machine, 200 l,

screen,

cover,

lter, oil and moisture separator CAF-3,

abrasive metering valve FSV.
