UNIOR d.d.

Kovaška cesta 10

3214 Zreče

SLOVENIJA

tel.: +386 (0) 3 757 81 00

fax: +386 (0) 3 576 26 43

email: sales@unior.si

www.uniortools.com

Used bushing (A) needs to be removed

from the shock • Obrabljeno pušo (A) je po-

trebno odstraniti iz amortizerja.

Size of the pin (B) is chosen upon the bu-

shing (C) size, either 12 mm or 12.7 mm

diameter. Tool is assembled as shown on

the picture above •

Velikost trna (B) izberemo glede na velikost

puše (C) ki jo moramo iztisniti. Puša je lahko

12 mm ali 12.7 mm premera. Orodje sestavi-

mo kot prikazuje zgornja slika.

Assembled tool together with the shock

is put into the vice. Bushing is now pres-

sed out of the shock with use of the vice.

Bushing is pushed into the bigger part of

tool, from where it can be easily removed

• Sestavljeno orodje in amortizer vpnemo v

primež in z enakomernim stiskanjem pušo

iztisnemo iz ohišja amortizerja. Puša se po-

makne v zaprt predel orodja, iz kjer jo eno-

stavno odstranimo.

New bushing is set parallely next to the

opening on the shock and put together

in the vice. With use of the vice, bushing

is pressed into the shock • Novo pušo pa-

ralelno postavimo na odprtino na ohišju

amortizerja in skupaj vstavimo v primež. Z

enakomernim stiskanjem poskrbimo da je

puša v celoti stisnjena v ohišje.

USAGE INSTRUCTIONS...
