MAINTENANCE / RECOMMENDATIONS
• The operators must have received suitable training in order to use the machine at its maximum potential and
weld correctly.
• Check which welding process is authorised by the manufacturer before attempting any vehicle repair.
• The maintenance and the repair of the . Any work undertaken by a third party on the generator will invalidate the warranty. The
manufacturer will not accept liability in the event of an incident that would occur after this work was undertaken.
• Ensure the machine is unplugged from the mains, and wait for two minutes before carrying out maintenance work. Inside, voltages
and currents are high and dangerous.
• All the welding tools will wear o with use. Ensure that these tools are clean to get the be results.
• Prior to using the gun, check the condition of the dierent tools (ar, single sided electrode, carbon electrode...) and clean or
replace if required.
• Remove regularly the casing and any excess of dust. Take this opportunity to have the electrical connections checked by a qualied
person, with an insulated tool.
• Regularly review the condition of the power cable and welding connection cables. In case of visible signs of damage, organise for
them to be replaced by the manufacturer or a qualied technician.
• Ensure the vents of the device are not blocked to allow adequate air circulation.
INSTALLATION – PRODUCT OPERATION
GENERAL DESCRIPTION
This product has been designed to carry out the following operations in a car body workshop: Dent pulling; welding of nails,
rivets, rings and pins; removal of bumps and dents; sheet stretching. It is not designed for the assembly of metal parts. This
device is delivered with an earth clamp, a gun (with cable), a consumables and accessories box, and an SOOW mains cable.
Accessories 2600 2700
3900 - 230 V 3900 - 400 V
PRO 230 V PRO 400 V
Earth plate
Separate gun lead
Automatic Quick Gun
Manual Quick Gun
Spotter Box
Spotter Box Pro
PRODUCT SPECIFICATIONS
2600 / 2700 3900 - 230 V 3900 - 400 V PRO 230 V PRO 400 V
ELECTRIC SPECIFICATIONS
U
1N
rated power supply voltage 1 ~ 230 V 1 ~ 230 V 2 ~ 400 V 1 ~ 230 V 2 ~ 400 V
Frequency 50/60 Hz
U
20
rated no load voltage 5.4 V De 0.5 à 7.4 V
Permanent power U
SP
1 kVA 1.8 kVA
Permanent supply current I
1p
4.7 A 9 A 5 A 9 A 5 A
Maximal current of a permanent primary short
circuit I
1cc
43 A 90 A 52 A 90 A 52 A
Maximal current of a secondary short circuit I
2cc
1800 A 2800 A
Permanent secondary current I
2p
200 A 270 A
Type of welding current
THERMAL SPECIFICATIONS
Operating ambient temperature De + 5°C à + 40°C
Storage and transport operating ambient De -25°C à +55°C
13
SPOT 2600 / 2700 / 3900 - 230 V
3900 - 400 V / PRO 230 V/ PRO 400 V
EN
Translation of the original instructions
