ENGLISH

or if they are not instructed by this person on

the usage of the unit.

• Do not leave the operating unit unattended.

• Unplug the unit if it is not being used and

before cleaning.

• Do not use inflammable, highly explosive,

toxic and cleaning solvents to remove dirt.

• When unplugging the unit, pull the plug but

not the cord.

• Do not touch the power plug with wet hands.

• Provide that the power cord does not contact

with hot surfaces and sharp furniture edges.

• Do not wind the power cord around the unit body.

• Check the cord insulation integrity periodi-

cally.

• Do not attempt to repair the unit. Do not disas-

semble the unit by yourself, if any malfunction

is detected or after it was dropped, unplug

the unit and apply to any authorized service

center from the contact address list given in

the warranty certificate and on the website

www.vitek.ru.

• Transport the unit in the original package only.

THE UNIT IS INTENDED FOR HOUSEHOLD

USAGE ONLY

BEFORE THE FIRST USE

After unit transportation or storage at low tem-

perature keep it for at least three hours at room

temperature.

ATTENTION! The convention fan-heater is intended

only for additional heating of rooms. It is not meant

for operation as main heating unit.

• Unpack the unit.

• Make sure that the operation mode switch (5)

is set to the position “0” (the unit is switched

off).

SETTING

Option 1 – Stand mode

• Turn the unit over. Combine openings on the

support plates (1) with wheels with relevant

openings in the lower part of the convection

fan-heater body (pic.1).

• Fix the support plates (1) with wheels using

screws for fastening the support plates (pic. 2).

• Turn the unit over and set it on the wheels.

Option 2 – Wall mounting

Attention! Before drilling a hole in the wall,

make sure that there is no electrical wiring at

this place.

• When mounting the unit on the wall, ensure

that the mains socket is below the level of

the unit and easy to access. Keep the follow-

ing gaps: between floor and unit – not less

than 15 cm, between front / upper panels

and objects – not less than 45 cm, between

side panels and objects – not less than 25

cm (pic. 7).

• Support plates (1) with wheels are not used for

wall mounting of the convection fan-heater.

• First mark holes on the wall (pic. 3).

• Drill the holes in the wall to the required depth.

• Insert the dowels into the drilled holes (pic. 4)

and fix screws for mounting the convection

fan-heater (pic.5).

• Hang the convection fan-heater (pic.6) using

wall brackets (6) on the back side of the unit.

Using the convection fan-heater

• Before switching the unit on, make sure that

your home mains voltage corresponds to the

unit operating voltage, and the switch (5) is in

the position “0” (the unit is switched off).

• Insert the power plug into the mains socket.

• Select the required convection fan-heater

operation mode using the switch (5):

– I – minimum heating power,

– II – maximum heating power.

Note:

– Model VT- 2171 has the operation mode

switch (5) with only two positions -“ I/O”.

Power capacity for models of сonvection

fan-heaters:

VT-2171 – I – 1000 W

VT-2172 – I – 750 W– II – 1500 W

VT-2174 – I – 900 W – II – 2000 W

• The indicator (3) will light up.

• You may set the required room air heating level

from minimum to maximum value (MIN/MAX)

by turning the temperature control knob (4).

• When the room temperature reaches the

required value, slowly turn the tempera-

ture control knob (4) counterclockwise until

the indicator (3) goes out. The preset tem-

perature will be maintained automatically.

If the room temperature is lower than the

temperature set by the temperature con-

trol knob (4), the unit will be switched to the

heating mode. When the preset tempera-

ture is reached, the unit will be switched to

the standby mode, once the air in the room

cools down, the unit will be switched to the

heating mode again.

IM VT-2171.indd 4 23.06.2016 14:23:12
