Инструкция к Karcher K4 Compact Basic Car 1,637-506 Страница: 9

Karcher K4 Compact Basic Car 1.637-506 Инструкция к Karcher K4 Compact Basic Car 1,637-506 онлайн [9/128] 816877

English 9

Extraction of water from public waterways is not

permitted in some countries.

Notes on the content materials (REACH)

Current information on content materials can be found

at: www.kaercher.de/REACH

Intended use

Use the high-pressure cleaner in private households

only.

The high-pressure cleaner is intended for cleaning ma-

chines, vehicles, buildings, tools, façades, terraces,

garden machines etc. using a high-pressure water jet.

Accessories and spare parts

Only use original accessories and original spare parts.

They ensure that the appliance will run fault-free and

safely.

Information on accessories and spare parts can be

found at www.kaercher.com.

Scope of delivery

The scope of delivery for the appliance is shown on the

packaging. Check the contents for completeness when

unpacking. If any accessories are missing or in the

event of any shipping damage, please notify your deal-

er.

Device description

The maximum amount of equipment is described in

these operating instructions. Depending on the model

used, there are differences in the scope of delivery (see

packaging).

For the illustrations, refer to the graphics page

Illustration A

1 Storage for spray lance

2 Storage for high-pressure gun

3 Transport handle, telescoping

4 Carrying handle

5 Quick coupling for high-pressure hose

6 Storage for high-pressure hose and mains connec-

tion cable

7 Power switch "0/OFF" / "I/ON"

8 Mains connection cable with mains plug

9 Carrying handle

10 Type plate

11 Transport wheel

12 Water connection coupling

13 Water connection with integrated sieve

14 Suction hose for detergent (with filter)

15 High-pressure gun

16 High-pressure gun lock

17 Button for separating the high-pressure hose from

the high-pressure gun

18 High-pressure hose

19 Vario Power spray lance for common cleaning

tasks. The working pressure can be continuously in-

creased from "SOFT" to "HARD". To adjust the

working pressure, release the trigger gun lever and

turn the spray lance to the desired position. Deter-

gent can be added to the water jet when the spray

lance is turned all the way in the SOFT direction.

20 Spray lance with dirt grinder for stubborn soiling

21 *Rotating washing brush (e.g. for washing cars)

22 **Garden hose with commonly available coupling

– Fabric reinforced

– Diameter of at least 1/2 inch (13 mm)

– Length at least 7.5 m

* optional, ** additionally required

Safety devices

몇 CAUTION

Missing or modified safety devices

Safety devices are provided for your own protection.

Never modify or bypass safety devices.

Power switch

The power switch prevents unintentional operation of

the device.

High-pressure gun lock

The lock locks the lever of the high-pressure gun and

prevents the device from starting unintentionally.

Auto-stop function

If the lever of the high-pressure gun is released, the

pressure switch turns off the pump and the high-pres-

sure jet stops. The pump switches on again when the le-

ver is pressed.

Motor circuit breaker

The motor circuit breaker shuts off the device if power

consumption it too high.

Symbols on the device

Installation

For the figures, refer to the graphics page.

Fit the supplied loose parts onto the device before start-

ing up the device.

Install the transport handle

1. Attach the transport handle.

Illustration B

Installing the water connection coupling

1. Screw the water connection coupling onto the water

connection on the device.

Illustration C

Initial startup

ATTENTION

Exceeding the maximum permissible grid impedance

Material damage

Take care not to exceed the maximum permissible grid

impedance on the connection point (see chapter Tech-

nical data).

Contact your electricity supplier in the case of any un-

certainties regarding the mains grid impedance at your

electrical connection point.

Do not aim the high-pressure jet may at

persons, animals, live electrical equipment

or the device itself.

Protect the device against frost.

The device may not be directly connected

to the public drinking water network
