The "TEST" button is designed to test the performance of the luminaire from the

battery in emergency mode.

If malfunctions are detected at the end of the warranty period or at the end of the

service life, dispose of the luminaire.

To operate the mechanically damaged luminaire.

Work on installation and maintenance of the product should be carried out by

specially trained personnel in compliance with the requirements of regulatory and

technical documentation in the field of electrical engineering.

IT IS FORBIDDEN

Safety measures

Indicating lights signals about: red colour – the battery is charging, green colour –

the battery is charged.

Rules and conditions for effective and safe use

The luminaire is supplied with a disconnected battery. To connect the battery, you

need to remove the diffuser from the luminaire, then remove (for DPA 2101, DPA 2105)

or shift (for DPA 2104) the reflector with LEDs, connect the conductors with a plug

coming from the battery to the corresponding pin connector on the control board.

To connect the luminaire to damaged wiring.

Before using the luminaire, familiarize yourself with the technical data, conditions

of safe and effective use (table 1).

To provide the degree of protection IP65, fix the DPA 2105 luminaire on the

mounting surface with the self-tapping screws through rubber sealing rings (included

in the delivery set).

ákіmshіlіk úı-jaılarda ylǵal men shań quramy tómen apattyq-evakýatsııalyq

jaryqtandyrýdy qamtamasyz etýge arnalǵan, sondaı-aq pıktogrammalar bolǵan kezde

evakýatsııalaý baǵytyn kórsetý úshіn paıdalanylýy múmkіn (jıyntyqqa kіrmeıdі).

Tıimdi jáne qaýipsiz paıdalaný erejeleri men sharttary

Ónim týraly negizgi aqparat

Jaryqdıodty apattyq shyraǵdandar (budan ári - shyraǵdandar) arnalǵan,

Shyraǵdandar KO TR 004/2011, KO TR 020/2011, EAEO TR 037/2016 jáne

MEMST IEC 60598-2-22 tehnıkalyq reglamentterіnіń talaptaryna sáıkes keledі.

Shyraǵdandy qoldanar aldynda tehnıkalyq derektermen, qaýіpsіz jáne tıіmdі

paıdalaný sharttarymen tanysyńyz (1-kestesі).

Buıymdy montajdaý jáne qyzmet kórsetý boıynsha jumystardy elektrotehnıka

salasyndaǵy normatıvtіk-tehnıkalyq qujattama talaptaryn saqtaı otyryp, arnaıy oqytylǵan

personal júrgіzýі tıіs.

"TEST" batyrmasy akkýmýlıatordan apattyq rejımde shyraǵdannyń jumys

qabіlettіlіgіn tekserýge arnalǵan.

Jaryq ındıkatorlary: qyzyl – batareıa zarıady, jasyl – batareıa zarıadtalǵan.

IP65 qorǵaý dárejesіn qamtamasyz etý úshіn DPA 2105 shyraǵdanyn montajdaý betіne

tyǵyzdaǵysh rezeńke saqınalar arqyly burandalarmen bekіtіńіz (ónіmnіń jetkіzіlіmіne kіredі).

Shyraǵdandar óshrlgen batareıamen birge keledi. Batareıany qosý úshin Siz

dıfýzordy shamnan alyp tastaýyńyz kerek, sodan keın (DPA 2101, DPA 2105 úshn)

nemese jaryq dıodtary bar shaǵylystyrǵyshty syrǵytyńyz (DPA 2104 úshin), basqarý

taqtasyndaǵy tıst stkshel konnektorǵa akýmýlátordan keletin shtepseldik ótkizgishterdi

qosyńyz.
