user manual
CROSS
LINE LASER
EN
user manual
CROSS
LINE LASER
EN
XLiner Pento 360/360G XLiner Pento 360/360G
8 9
TECHNICAL SPECIFICATIONS
XLiner
Pento 360
XLiner
Pento 360G
Working range/with receiver 40/100 m* 60/100 m*
Accuracy ±0,2 mm/m
Self-leveling range ± 3,5°
Continuous operating time >18 hours >8 hours
Operating temperature -10°C ... +50°C
Storage temperature -20°C ... +70°C
Relative humidity 90%
Dust and water protection rate IP54
Thread for mounting on a tripod 1/4’’ and 5/8’’
Laser
Class II 635 nm
< 1 mW
Class II 515 nm
< 1 mW
Power supply 7.4V 2600 mAh Li-ion
Dimensions 155x85x132 mm
Weight:
without battery
with battery
0,63 kg
0,73 kg
* The operating range may differ from the declared depending on the
lighting conditions.
BEFORE START OPERATION
Power supply
The laser level is powered via a 7.4V 2600mAh Li-ion battery included
in the delivery package.
Install/charge the Li-ion battery
Install the battery in the battery compartment, observing the polarity.
Use the battery included in the delivery package only.
If the power indicator on the control panel starts flashing red, the
battery must be charged.
The charging procedure is as follows:
1) Remove the battery from the laser level.
2) Connect the battery to the power source by a charging cable,
included in the delivery package. The power indicator on control
panel will be red while charging.
3) The battery charging time is about 3 hours.
4) Once the power indicator on control panel turns green, disconnect
the charger and install the battery in the battery compartment.
OPERATION
Place the laser level on a firm and stable surface or a tripod.
Move switch bar to select required operating mode:
1) Automatic leveling:
Move the switch bar to position ON.
The laser level will switch on.
Short press to switch on required lines. If the laser level is out
of the range of automatic compensation laser lines will flash 1 time
per second.
Short press to switch on/off the pulse mode.
To switch off the laser level move the switch bar to position OFF.
