4
ENGLISH
Explanation of general view
1-1. Cutting action changing lever
2-1. Switch lever
3-1. Speed adjusting dial
4-1. Tool opener
5-1. Blade clamp
5-2. Jig saw blade
5-3. Protrusions
6-1. Jig saw blade
7-1. Base
7-2. Hex wrench
8-1. Cutting line
8-2. Base
10-1. Base
10-2. Bolt
10-3. Hex wrench
11-1. Graduation
11-2. Bevel slot
11-3. Base
11-4. Gear housing
11-5. V-notch
11-6. Bolt
12-1. Base
12-2. Bolt
12-3. Hex wrench
13-1. Starting hole
16-1. Dust nozzle
16-2. Base
18-1. Dust nozzle
18-2. Hose for vacuum cleaner
19-1. Rip fence
20-1. Hex wrench
20-2. Bolt
20-3. Fence guide
22-1. Fence guide
22-2. Threaded knob
22-3. Circular guide pin
24-1. Bolt
24-2. Rule bar
25-1. Screw
25-2. Guide rail adapter
25-3. Guide rail
26-1. Cover plate
26-2. Base
27-1. Base
27-2. Anti-splintering device
SPECIFICATIONS
Model 4351T 4351CT 4351FCT
Length of stroke 26 mm 26 mm 26 mm
Wood 135 mm 135 mm 135 mm
Steel 10 mm 10 mm 10 mm
Max. cutting capacities
Aluminum 20 mm 20 mm 20 mm
Strokes per minute (min
-1
) 2,800 800 - 2,800 800 - 2,800
Overall length 271 mm 271 mm 271 mm
Net weight 2.4 kg 2.5 kg 2.5 kg
Safety class /II
• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Note: Specifications may differ from country to country.
END201-2
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･ Read instruction manual.
･ DOUBLE INSULATION
･ Only for EU countries
Do not dispose of electric equipment
together with household waste material!
In observance of European Directive
2002/96/EC on waste electric and
electronic equipment and its
implementation in accordance with
national law, electric equipment that
have reached the end of their life must
be collected separately and returned to
an environmentally compatible
recycling facility.
ENE019-1
Intended use
The tool is intended for the sawing of wood, plastic and
metal materials. As a result of the extensive accessory
and saw blade program, the tool can be used for many
purposes and is very well suited for curved or circular
cuts.
ENF002-1
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated in accordance with European
Standard and can, therefore, also be used from sockets
without earth wire.
For Model 4351T
ENG101-1
For European countries only
Noise
The typical A-weighted noise level determined according
to EN60745-2-11:
Sound pressure level (L
pA
) : 85 dB(A)
Uncertainty (K) : 3 dB(A)
The noise level under working may exceed 85 dB (A).
Wear ear protection.
ENG220-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN60745-2-11:
Work mode : cutting chipboard
