AUTO DISPENSER
AUTO SANITIZER
HÖR-DE-006A
AUTO SOAP DISPENSER
HÖR-DE-006B
USER MANUAL
A Size: 128 × 112 × 284 mm
Weight: 0.85 kg
D ATTENTION! Turn off the device before opening the cover!
Insert batteries observing polarity starting from the far row.
*Power supply and batteries are not included in the
standard device set.
E Dowels and screws are supplied in the set. For installation, use the
holes on the rear wall as shown in the figure.
G Before using, fill in the system with liquid by several idle operations.
F *The stand is not included in the set and may be supplied separately.
We recommend models HÖR-50 and HÖR-777701.
B ATTENTION! Turn off the device before opening the cover!
Do not use acetone-containing liquids!
Do not diassamble the electronics module!
C ATTENTION! Do not use any reflective surfaces under the
device, the minimum distance to any obstacle is 300 mm
H • UV radiation
•Two-color indicator: green means that the device is turned on and
working; red indicates a low battery level or long stay of an
obstacle in the sensor triggering zone.
• Sensor response area is 80 ± 30 mm.
1000 ML
750 ML
650 ML
250 ML
Connection socket
4 batteries type C (LR14)
1.5 V (ø 26.2 mm; h = 50
mm) You can also use the
network power adapter.
Adapter parameters:
АС / DC, 6 V, 1000 mA or more,
Jack connector: 5.5 x 2.1 or
5.5 x 2.5; plus in the centre.
AUTOMATIC DISPENSER
INSTALLATION
Workspace
area
INSTALLING BATTERIES
SPRAY DROP
*These holes can be used for mounting
the device to a stand.
Correct
INSTALLATION ON SCREW
WORKING AREA
Working zone: 30 cm
STAND MOUNTING
Incorrect
Refillable container
Installing the pump in holder
