Element 100 Manual Original Instructions Dec 2016
6
4) SPECIFICATION
Maximum hole cutting capacity in .2/.3C steel = 100mm dia. x 100mm deep
Arbor bore = MT3.
Motor Unit
Voltages
110V 50-60Hz
230V 50-60Hz
Normal full load
19.7 A
2000 W
9.5 A
2000 W
Electro Magnet
0.92 A
96W
0.5 A
109W
Size
Holding Force at 20°C with 25mm minimum plate thickness
The use on any material less than 25mm thick will progressively
reduce the magnetic performance. If possible, substitute
material should be positioned under the magnet and work
piece to equate to a suitable material thickness. If this is not
possible, an alternative secure method of restraining the
machine must be used.
Total Load (magnet + motor)
2096W
2109W
Overall Dimensions
Height - maximum extended
Height - minimum
Width (including capstan fitting)
Length Overall (including guard)
Nett Weight
24.8kgs
24.5kgs
Element 100/1T
Element 100/3T
Vibration total values (triax vector sum) in accordance with
EN61029-1:
Vibration emission value
(a
h
):3.862m/s
2
Uncertainty(K):1.5m/s²
Vibration emission value
(a
h
):3.824 m/s²
Uncertainty(K):1.5m/s²
Level of sound pressure in accordance with EN61029-1:
Sound pressure(LpA):
89.0 dB(A)
Acoustic power(LwA):
102.0 dB(A)
Uncertainty(K)：3dB(A)
Sound pressure(LpA):
88.0 dB(A)
Acoustic power(LwA):
101.0 dB(A)
Uncertainty(K)：3dB(A)
Ear and eye defenders must be worn when operating this machine. Wear gloves to protect hands when operating the
machine.
The declared vibration total value has been measured in accordance with a standard test method and may be used for
comparing one tool with another.
The declared vibration total value may also be used in a preliminary assessment of exposure.
The vibration emission during actual use of the power tool can differ from the declared total value depending on the
ways in which the tool is used;
The need to identify safety measures to protect the operator that are based on an estimation of exposure in the
actual conditions of use (taking account of all parts of the operating cycle such as the time and when the tool is
switched off and when it is running idle in addition to the trigger time).
These tools are UK designed and manufactured with globally sourced components and conform with the requirements
of EEC Document HD.400.1 and BS.2769/84.
Suitable only for a single phase 50-60Hz A.C. power supply
DO NOT USE ON D.C. SUPPLY
Do not use your magnetic drill on the same structure when arc welding is in progress.
D.C. current will earth back through the magnet and cause irreparable damage.
WARNING: THIS APPLIANCE MUST BE EARTHED!
NB: ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE
