Table 1 - The main technical data of contactors КМE-0910, КМE-0901, КМE-1210,

КМE-1201, КМE-1810, КМE-1801

Parameters

KME-0910,

KME-0901

KME-1210,

KME-1201

KME- 1810,

KME-1801

Rated power, kW

<+40С,

230V

АС-3

2,2 3 4

<+40С,

400V

4 5,5 7,5

<+40С,

660V

5,5 7,5 10

Rated operating current, А

<+40С,

400V

АС-3 9 12 18

АС-1 25 25 32

Number of poles 3Р

Available auxiliary contacts 1NO, 1 NC

Maximum short-time load (t<1c), A 162 216 324

Rated AC operating voltage, Ue, V 230, 400, 660

Rated impulse voltage, Uimp, kV 6

Rated insulation voltage, Ui, V 690

Conventional short-circuit current, Inc, A 1000 3000

Dissipation power at Ie, W/pole

АС-3 0,2 0,36 0,8

АС-1 1,56 1,56 2,5

Rated voltage of control coil, Uc, V 230, 400

Control voltage ranges

tripping (0,8 - 1,1)*Uc

release (0,3 - 0,6)*Uc

Power consumption of control coil

at Uc, VA

tripping cos f = 0,75 60 60 60

holding cos f = 0,3 7 7 7

Tripping time of control coil, ms

closing 12-22 12-22 12-22

opening 4-19 4-19 4-19

Power dissipation of control coil, W 3 3 3

Switching endurance of control coil,

mln. cycles

АС-3 1,65 1,65 1,65

АС-1 1,43 1,43 1,43

Mechanical endurance mln. cycles 15 15 15

Overall dimensions, mm

width 45 45 45

height 74 74 74

depth 80 80 80

Connection of power circuit, mm

exible cable 1-4 1-4 1,5-6

rigid cable 1,5-4 1,5-4 2,5-6

tightening torque, Nm 1,5 1,5 1,5

Connection of control circuit, mm

exible cable 1-4

rigid cable 1-4

tightening torque, Nm 1,5

Main accessories for contactors

add-on contact blocks

PKE-02, PKE-04, PKE-11,

PKE-20, PKE-22, PKE-40

time relay

PVE-11, PVE-12, PVE-13,

PVE-21, PVE-22, PVE-23

interlocking devices Mechanical interlocking up to 32A

thermal overload relay

RTE-1305 RTE-1306 RTE-1307

RTE- 1308, RTE-1310 RTE-1312

RTE-1314 RTE-1316 RTE-1321
