6 - 2CDC002157D0202
Miniature Circuit Breaker S 200/S 200 M
Internal resistance and power loss
Rated Tripping characteristic
current B, C
1)
D K Z
Internal
resistance
Power loss Internal
resistance
Power loss Internal
resistance
Power loss Internal
resistance
Power loss
I
n
R
i
P
v
R
i
P
v
R
i
P
v
R
i
P
v
A mΩ W mΩ W mΩ W mΩ W
0.5 5500 1.4 4300 1.1 4300 1.1 8100 2.4
1.0 1440 1.4 1250 1.25 1250 1.25 2100 2.3
1.6 630 1.6 600 1.5 600 1.5 1000 2.8
2.0 460 1.8 410 1.6 410 1.65 619 2.5
3.0 150 1.3 130 1.2 130 1.2 235 2.4
4.0 110 1.8 105 1.7 105 1.7 149 2.4
6.0 55 2.0 52 1.9 52 1.9 75 3.2
8.0 23 1.5 24 1.5 24 1.5 27 2.0
10.0 19 2.1 16 1.6 13.5 1.4 24 2.7
13.0 14 2.3 14 2.2 13.5 1.4 — —
16.0 8.5 2.5 8.5 2.5 7.7 2.0 10.9 2.8
20.0 6.25 2.5 6.1 2.3 6.7 2.7 6.0 2.4
25.0 5.0 3.2 4.3 3.1 4.6 2.9 4.5 3.3
32.0 3.6 3.7 3.5 3.6 3.5 3.6 3.5 3.6
40.0 3.0 4.8 2.2 4.2 2.2 4.2 2.5 4.1
50.0 1.3 3.25 1.25 2.9 1.25 3.1 1.5 4.1
63.0 1.2 4.8 1.2 4.8 1.0 4.4 1.3 5.2
1)
Current ratings 0.5 – 4 A, 8 A apply to C characteristic only
Internal resistances are subject to application-specific and environment-specific conditions and are therefore to be
considered as typical values.
Internal resistance and power loss per pole
