Circuit Breaking
Capacity (I
cu
)
10 kA Rated Conditional Short-
Circuit Current (I
nc
)
0 kA Maximum Surge Current
AC Leakage Current Type
50 Hz Frequency (f)
50 Hz Rated Frequency (f)
Average per Pole 2.3 W
Phase Pole 3.4 W
Neutral Pole 1.2 W
Total 4.5 W
Power Loss
Arbitrary Power Supply
Connection
10000 cycle Electrical Endurance
20000 cycle Mechanical Endurance
2 Number of Poles
1 Number of Protected
Poles
Instantaneous Operating Characteristic
III Overvoltage Category
Right Position of Neutral
Terminals
No Accessories Available
Busbar 10 mm²
Rigid 25 ... 25 mm²
Flexible 25 ... 25 mm²
Connecting Capacity
Environmental
Operation -25 ... +55 °C
Storage -40 ... +70 °C
Ambient Air
Temperature
IP2X Degree of Protection
2 Pollution Degree
Following EU Directive 2011/65/EU RoHS Status
9AKK107492A2001 RoHS Information
9AKK108467A9482 REACH Declaration
9AKK108468A3363 Conflict Minerals
Reporting Template
(CMRT)
Dimensions
2 Width in Number of
Modular Spacings
0.035 m Product Net Width
0.085 m Product Net Height
0.069 m Product Net Depth /
Length
0.182 kg Product Net Weight
69 mm Built-In Depth (t
2
)
Ordering
box 1 piece Package Level 1 Units
0.207 kg Package Level 1 Gross
Weight
2
DSH201 C16 AC30
© 2023 ABB. All rights reserved.Subject to change without notice 2023/11/17
