Basic settings

• White Balance. In this parameter, you can adjust the color temperature. The default option is "Auto White Balance".

• Exposure. In "Auto Exposure", you can set the exposure value. In "Manual Exposure", you can adjust the "time" parameter.

• Color Adjustment. In this parameter, you can adjust saturation, hue, brightness, and contrast.

• Monochrome. By selecting this parameter, you will see the image in dierent tones of a single color (e.g. shades of gray).

• Flip. This feature allows you to ip the image horizontally or vertically.

Measurements

1. Cross Line. You can select a cross line in four colors, turn the display on or o, and adjust the position of the center point of

the cross line.

2. Calibration. The camera is calibrated by default, but you may need to recalibrate the camera.

• Put the calibration slide on the stage so that the scale is placed horizontally on the screen. Adjust the focus as clearly as

possible.

• Enter the Calibration menu. Drag a segment of the calibration ruler so that its ends are next to the marks on the physical

scale of the calibration slide. For maximum accuracy, try to capture as many scales as possible.

• Example: The image above uses a ruler with 0.01mm (10µm) divisions under a 10x lens. The camera parameters are set

to: "magnication 10x", "units μm", and "length 40".

• Each objective lens must be calibrated to take measurements at dierent magnications.

• After adjusting the parameters, exit the calibration menu to complete the procedure.

3. Recalibration. The calibration process has to be repeated if the magnication or focus has been changed during

observations. Enter the Measurement menu. Select the magnication, adjust the start and end point, and then the value of

the measured segment will be displayed.

Fuse replacement (Levenhuk D95L LCD)

Unplug the microscope from a power source. Open the fuse holder located on the back of the microscope body with a at head

screwdriver. Remove the old fuse and install a new one. Only use the appropriate types of fuses. Close the fuse holder.

Specications

Product ID 78902 78903

Model Levenhuk D85L LCD Levenhuk D95L LCD

Type biological/optical, digital

Research method bright eld

Magnication 60x, 150x, 600x 60x, 150x, 600x,1500x

Eyepiece head 7" color LCD screen

Optics material optical glass

Objectives achromatic: 4x, 10x, 40x achromatic: 4x, 10x, 40xs, 100xs (oil)

Revolving nosepiece 3 objectives 4 objectives

Stage moving range — 70/30mm

Stage 90x90mm, with specimen holders

double layer mechanical, 110x126mm,

with mechanical scale

Focus system coaxial, coarse (15mm) and ne (0.002mm)

Condenser

N.A. 0.65 with diaphragm disk

(6 apertures)

Abbe N.A. 1.25 iris diaphragm and lter

holder

Body metal

Illumination

upper and lower (0.2W LED) with

brightness adjustment

lower (1W LED) with brightness

adjustment

Collector + +

Filters — blue, green, yellow

Vial of immersion oil — +

Fuse — +

Power supply

3pcs AA batteries or 110—220V, via AC

adapter

110—220V, via AC adapter
