SAFETY NOTES FOR MIXERS | TOOL PARTS OVERVIEW

BEFORE USE

• Hold the device by the insulated handle surfaces when performing work where there is

danger of the applied tool striking hidden electical lines or its own power line. Contact

with a live wire could cause metal parts of the device to become live and lead to

electric shock.

• Do not use device in surroundings with explosive atmospheres. Do not mix solvents or

substances containing solvents with a ashpoint below 21 °C.

• Do not place cables around any part of your body.

• Only turn the device on or o when it is in the mixing vessel. Make sure that it is

securely and safely positioned. When mixing, do not place hands or objects in the

mixing vessel.

• If the sound pressure level at the work station exceeds 85 dB(A), wear hearing

protection!

• Wearing work gloves and safety glasses is recommended when working with the

agitator.

• Wearing snug tting clothing is required.

Always pull the mains plug before executing settings on the device.

Mounting the agitator (Fig. B)

• Firmly screw the shaft to the mixing spiral.

• Subsequently, screw the agitator 7 into the agitator shaft with the M-14 inner

threading 4 .

• Secure the chuck with an open-end spanner 2 and tighten the stirrer 7 with a second

openend spanner 2 .

Dismantling the agitator

• To remove the agitator, repeat the process in the reverse order.

Installing the auxiliary handle

• Install the auxiliary handle 3 by securing the 2 included screws in the designated

location on the gearbox housing (see Fig. C).

SAFETY NOTES FOR MIXERS

BEFORE USE

TOOL PARTS OVERVIEW

1. Handle

2. Open-end spanner for changing

agitator

3. Auxiliary handle

4. Agitator shaft M14 inner threading

5. On/o switch

6. Lock-on button

7. Mixing paddle

8. Rotation speed adjustment wheel
