– 8

You can rectify minor faults yourself with the help

of the following overview.

If in doubt, please consult the authorized cus-

tomer service.

 Danger

Turn off the appliance and remove the mains

plug prior to any care and maintenance work.

Repair works may only be performed by the au-

thorized customer service.

Î Pull on the lever of the trigger gun; the device

will switch on.

Î Check whether the voltage indicated on the

type plate corresponds to the voltage of the

mains supply.

Î Check the mains connection cable for dam-

ages.

Î Appliance ventilation: Switch the appliance

on with the high-pressure hose detached

and operate (max. 2 minutes) until the water

exits the high-pressure connection without

bubbles. Switch off appliance and reconnect

high-pressure hose.

Î Check the water supply.

Î Pull out the sieve in the water connection us-

ing flat-nose pliers and clean under running

water.

Î Clean high-pressure nozzle: Remove dirt

and debris from the nozzle bore, using a

needle and rinse through with water from the

front.

Î Check water flow quantity.

Î Slight leakage from the appliance pump is

normal. If the leakage increases contact the

authorized customer service.

Î Detach spray lance from the trigger gun.

Work only with the trigger gun.

Î Clean the detergent suction hose filter.

Î Check the detergent suction hose for kinks.

Subject to technical modifications!

Troubleshooting

Appliance is not running

Pressure does not build up in the appliance

Strong pressure fluctuations

Appliance is leaking

No detergent infeed

Technical specifications

Electrical connection

Voltage 220-240

1~50/60

Power consumption 6 A

Protection class IP X5

Protective class II

Mains fuse (slow-blow) 10 A

Water connection

Max. feed temperature 40 °C

Min. feed volume 8 I/min

Feed pressure 0,2-1,2 MPa

Performance data

Working pressure 8 MPa

Max. permissible pressure 11 MPa

Water flow rate 5,5 I/min

Detergent flow rate 0,3 I/min

Recoil force of trigger gun 10 N

Dimensions and weights

Length 302 mm

Width 248 mm

Height 620 mm

Weight, ready to operate with

accessories

5,4/6,0 kg

Values determined as per EN 60335-2-79

Hand-arm vibration value

Uncertainty K

<2,5

0,3

m/s

Sound pressure level L

Uncertainty K

dB(A)

Sound power level L

+ Uncer-

tainty K

89 dB(A)

15EN
