The scope of delivery of the device (depending on the

model) is illustrated on the packaging. These operating

instructions describe all possible options.

Illustrations on Page 2

1 Coupling element for water connection

2 Quick coupling for high pressure hose

3 Storage for trigger gun

4 Water connection with integrated sieve

5 Appliance switch „0/OFF“ / „I/ON“

6 Dosage regulator for detergent

7 Storage for trigger gun

8 Transport handle

9 Storage of Plug 'n' Clean detergent bottle with de-

tergent connection

10 Plug 'n' Clean detergent bottle with locking lid

11 Storage for high pressure hose

12 Storage hook for mains connection cable

13 Storage for spray lance

14 Mains cable with mains plug

15 Transport wheel with wheel cap

16 Trigger gun

17 Lock trigger gun

18 Key to detach the high pressure hose from the trig-

ger gun

19 High pressure hose

20 Spray lance with Dirtblaster

For strong contaminations.

21 Spray lance with pressure regulation (Vario Power)

Carrying out the most common cleaning tasks.

The working pressure can be continuously in-

creased from "SOFT" to "HARD". To adjust the

working pressure, release the trigger gun lever and

turn the spray lance to the desired position.

Suitable for use with detergents.

Mount loose parts delivered with appliance prior to start-

up.

Illustrations on fold-out pages!

Illustration

 Push the wheels into the intake and secure them

with the plugs. Align the plug properly.

Illustration

 Place the bottom holder into the recesses and push

forward until it audibly locks in.

 Insert the top holder and push down all the way.

You will need the 2 included screws as well as a Phillips

screwdriver PH 2.

Illustration

 Slide the transport handle into the guide and se-

cure it with 2 screws.

You will need the 2 included screws as well as a Phillips

screwdriver PH 2.

Illustration

 Insert both detergent hoses onto the hose fittings.

Illustration

 Install the dosage regulator and connect using 2

screws.

Note: During installation you must make sure that

the tongues of the dosage regulator match up with

the intended recesses in the casing.

Description of the Appliance

* Optional

22 Washing brush

Suitable for use with detergents.

23 Rotary washing brush

Especially suitable for cleaning cars.

24 Foam nozzle with detergent container

With powerful foam for effortless cleaning.

** Additionally required

25 Fabric-reinforced water hose with commercially

available coupling.

– Minimum diameter, 1/2 inches (13 mm).

– Minimum length 7.5 m.

Assembly

Install wheels

Install the storage for trigger gun

Install the transport handle

Install the dosage regulator for detergent

12 EN
