With Levenhuk LabZZ MT2 Microscope you will make lots of interesting discoveries and create exciting memories! Remember

that following safety rules is absolutely necessary. In the kit you will ﬁnd the microscope, as well as many useful accessories.

Everything in place? Check it together with your parents.

Welcome to the microworld!

Eyepiece. You observe the magniﬁed image of the sample through the eyepiece. Eyepiece is a lens system that works the same

way as a magnifying glass.

Focusing knob. Blurry images? Rotate the knob gently, adjusting the focus until all details become clear. Be careful – rotate

the knob slowly so as not to damage the objective or observed slide.

Monocular head. This is a very important part of the microscope. The light travels right up the tube of the head directly into

the eyepiece, where the resulting image is formed.

Revolving nosepiece. This is a device that holds three objectives with different magniﬁcations. To change magniﬁcation,

rotate the nosepiece until it clicks (the sound means that the chosen objective is in place).

Objective. This is needed for magnifying images. Levenhuk LabZZ MT2 Microscope comes with three objectives with different

magniﬁcations. They magnify images 75, 300 and 900 times compared to what you see with the naked eye.

Stand. This curved part of the microscope connects all other parts together. If you are feeling uncomfortable looking through

the eyepiece, tilt or lift the stand until it's more comfortable. Change the inclination angle slowly, without abrupt movements.

Stage. This is exactly where you place the slide in order to observe it.

The stage has two , which, as is clear from their name, hold slides in place.slide holders

The mirror is located under the stage. It refracts the light from the lamp or the window illuminating the sample on the stage.

Illumination lamp. If illumination in your room is not enough, turn on the built-in illumination by turning over the mirror.

Battery compartment. The battery compartment is in the base of the microscope. What's it for? That's simple — it's where you

10.

11.

Microscope's construction

First install batteries for illumination. Flip the microscope over and remove the cap from the battery compartment. Insert two

AA batteries (those are not the thinnest penlight batteries, but those that are a bit thicker). Insert the batteries according to

their polarity — make sure that the “+” sign on the battery matches “+” in the compartment (same goes for “-” signs). Put

the cap back on. Don't hesitate to ask adults for help if you are not sure.

Place the microscope on the ﬂat surface near the source of bright light (window or a lamp). Turn the mirror towards the

illumination source. You should see a bright light spot through the eyepiece.

Now the microscope is ready for work.

Take a prepared microscope slide, place it on the stage and secure with holders.

Choose the objective by rotating the revolving nosepiece. The microscope comes with three objectives with different

magniﬁcations. The longer the objective, the higher magniﬁcation it produces. Most observations are better performed with

lower magniﬁcation, so choose the shortest objective to start. You will hear a “click” when the objective is in place.

Slowly rotate the focusing knob so the objective is almost touching the slide. BUT! It shouldn't actually touch the slide as both

the slide and the objective may be damaged if it does. That's why you need to do everything very slowly and carefully. When

the objective is very close to the slide (but doesn't touch it!), look through the eyepiece and start to rotate the focusing knob in

the opposite direction very slowly until you see a clear image.

How to work with the microscope

CAUTION! Never direct the mirror towards the Sun, as it may ruin your eyesight and even cause blindness.

џ Do not disassemble batteries.

џ Remember to switch off devices after use.

џ Keep batteries out of the reach of children, to avoid risk of ingestion, suffocation, or poisoning.

џ Utilize used batteries as prescribed by your country laws.

Wonderful telescope

Objective. The most important part of the telescope. The objective is a lens system that gathers light from the distant object

and forms its image. The objective should always be pointed in the direction of the object you want to observe.

Optical tube. Light rays collected by the objective travel down the optical tube to enter the eyepiece.

Eyepiece. You look at the Moon, planets and stars through the eyepiece. The eyepiece enlarges images of objects many times;

that's why all objects look bigger than when observed with the naked eye.

Sun shade. The shade is a short tube that is put on the objective. It's needed to not let the light from street lamps, car lights,

windows and other close-by light sources get in the objective and ruin the resulting image of the object you want to observe.

Finderscope — is a small telescope that is attached to the tube of the big telescope. The ﬁnderscope has small magniﬁcation

and wide ﬁeld of view (the latter means that you can see larger areas at once). The ﬁnderscope is made to help you ﬁnd the

desired object more quickly and easily. After you've found the object using the ﬁnderscope, you can observe it in detail

through the telescope.

Finderscope bracket is required to attach the ﬁnderscope to the telescope tube.

Focuser — is a special device in which the eyepiece is inserted. The focuser is needed for bringing the eyepiece closer or

farther from the objective. By doing so, you can achieve the maximum clarity of images.

Telescope's construction
