6English

Symbols on the device

Device description

For the illustrations, refer to the graphics page

Illustration A

1 Extension tube

2 Rotor arm height adjustment

3 Casing

4 Bayonet connector with union nut

5 Handle

6 High-pressure nozzle

7 Rotor arm

Extension tube installation

Note

Ensure that the device components are tightly connect-

ed on installation.

Illustration B

1. Plug the bayonet into the mounting.

2. Turn the extension until it latches into place.

3. Tighten the union nut.

Repeat the procedure for all further extension tubes.

Initial startup

Selection of the high-pressure nozzles

Using the appropriate high-pressure nozzles is a pre-

requisite for fault-free operation.

Note

These are to be selected according to the flow rate (l/

min). Information on the flow rate is provided in the op-

erating instructions or on the type plate of the high-pres-

sure cleaner.

Note

The yellow high-pressure nozzles are already fitted.

Operation

Note

The extension tubes can be used with all Kärcher ac-

cessories.

Note

For optimum cleaning results, do not operate the high-

pressure cleaner in the Eco mode.

Cleaning floors

Remove coarse dirt from the surface to be cleaned (e.g.

by sweeping) before using the device to avoid damage

to the T-Racer.

ATTENTION

Damage to the rotor arm

The rotor arm can be damaged if it hits edges and cor-

ners.

Do not move the device over free-standing corners and

edges.

Illustration C

Note

● The T-Racer is not suitable for scraping or scrub-

bing.

● Test the device on an inconspicuous area before us-

ing on sensitive surfaces, e.g. wood.

● Do not allow it to remain in one area, but keep it in

motion.

1. Attach the T-Racer to the high-pressure gun using

the extension tube.

Illustration B

a Press the extension tube onto the bayonet con-

nector of the high-pressure gun.

b Turn the extension tube by 90° until it latches into

place.

c If necessary, repeat the procedure for further

connections.

2. Adjust the rotor arm height adjustment. according to

the surface to be cleaned.

3. Unlock the lever of the trigger gun.

4. Pull the lever of the trigger gun.

The device switches on.

5. Clean the floor surface by guiding the T-Racer over

the floor surface without exerting excessive pres-

sure.

Cleaning wall surfaces

1. Attach the T-Racer directly to the high-pressure gun.

a Press the bayonet connector of the T-Racer into

the connection on the high-pressure gun and

then turn by 90° until it latches into place.

b Tighten the union nut if present.

2. Clean the wall surface.

Rotor arm height adjustment

The clearance of the high-pressure nozzles to the sur-

face to be cleaned can be adjusted via the rotor arm

height adjustment.

Adjust the rotor arm height adjustment. according to the

surface to be cleaned.

Illustration D

For powerful cleaning of stubborn soiling on dura-

ble surfaces, e.g. tiles, concrete, stone:

1. Set the rotor arm height adjustment to "HARD".

For cleaning sensitive surfaces:

2. Set the rotor arm height adjustment to "SOFT".

After use

Rinse off the device with a gentle water stream after use.

 Detach the T-Racer and any extension tubes fr

he high-pressure gun.

 Rinse off the T-Racer with the high-pressure gun (with-

out accessories) or wipe down with a damp cloth.

Storage

Store the device in a frost-protected place.

 DANGER

Risk of injury! Never reach under the

edge of the T-Racer during operation

HARD For durable surfaces, e.g. tiles, concrete,

stone

SOFT For sensitive surfaces, e.g. wood

Flow rate l/min (l/h) High pres-

sure class

(e.g.)

Colour of the

high-pressure

nozzles

Less than 5.8 (348) K2 - K3 Green

5.8 (348) - 7.5 (450) K3 - K5 Grey

Greater than 7.5 (450) K6 - K7 Yellow
