Derating Curve Static Characteristics
Mechanical Specification
1
2
4
3
35
35
167
167
Ul2464 16AWGx4C 1000±50mm for 12V
UL2464 16AWGx2C 1200±50mm
6767
Power LED
Power LED
30±3mm
30±3mm
C"+"
InsideOutside
11
AMBIENT TEMPERATURE (℃)
LOAD (%)
-30
2010 30 40
20
40
80
60
100
605045 70
INPUT VOLTAGE (VAC) 60Hz
85 10095 120110 160140 200180 240220 264
LOAD (%)
85
100
80
70
60
50
40
(HORIZONTAL)
50
230VAC
100VAC
Ul2464 18AWGx4C 1200±50mm for 15~48V
GST120A series
Case No. GS120A Unit:mm
120W AC-DC Reliable Green Industrial Adaptor
-V connected to AC FG
-V connected to AC FG
PIN NO.
1
2
3
4
OUTPUT
+Vo
-Vo
-Vo
+Vo
2
3
1
4
AC FG
2
1 4
3
KYCON KPPX-4P equivalent
DC output plug
◎ Standard plug
R7B
Pin Assignment
P1M
2.5
5.5
Pin Assignment
C"+"
InsideOutside
AC Inlet
IEC320-C14
11± 0.5mm
File Name:GST120A-SPEC 2020-08-03
