GST160A seri e s
160W AC-DC Reliable Green Industrial Adaptor
File Name:GST160A-SPEC 2020-10-20
Type No.
A
B
C
OD ID
L
P1M
5.5
2.5
11.0
P1J
5.5
2.1
11.0
Tuning Fork Style
B
A
C
(Straight)
Quick Adapter
Accessory
Type No.
MOLEX 39-01-2060 (4.2mm) equivalent
Pin Assignment
PIN No.
Output
1
2
3
4
5
+Vo
+Vo
-Vo
+Vo
-Vo
321
654
6
-Vo
C6P
MIC4
Pin Assignment
1
2
PIN No.
Output
NEUTRIK XLR NC4FX equivalent
3
4
Type No.
+Vo
+Vo
-Vo
-Vo
4
1
3
2
R1B
2
5
3
1
4
1
2
4
3
R7BF
+Vo
-Vo
Type No.
KYCON KPJX-CM-4S equivalent
Pin Assignment
PIN No.
Output
1
2
3
4
+Vo
-Vo
Min. DIN 4 Pin with Lock (female)
None
-Vo
-Vo
Type No.
Pin Assignment
PIN No.
Output
1
2
3
4
-Vo
+Vo
None
DIN 5 Pin (male)
5
+Vo
None
None
FG not connected to output connector
Available for 24 ~ 48V
◎ Optional DC plug: (Available in customized cable or quick adapter)
◎ DC plug changeable through:
(1) Customization of the standard part with an optional DC plug according to the table (MOQ applicable)
(2) Quick adapter accessory (sold separately without MOQ)
Please refer to below table and online selection guide :
Example quick adapter accessory:
(Current rating: 7.5A max.)
