When maintaining the shower bath, only wipe the painted parts, glass and plastic, using a fine cloth and normal household

detergents. Never use abrasive pastes, solvents, acetones or similar substances. The manufacturer is not responsible for

damage caused by inappropriate use, installation or maintenance of the product. The manufacturer is entitled to continuous

innovation of the product. For all other information concerning the mounting, use and maintenance, ask your salesperson.

We recommend the use of the RAVAK SERIES of speciality chemicals

Ecologically dispose of the packaging materials and after the service life of the radiator is finished, properly dispose of the

radiator as well. The reusable parts of the packaging materials such as the carton, tape and PE foil can be reused again

instead of recycling them. The non-recyclable parts of the packaging and later, the radiator itself should be disposed of in

a safe and proper manner according to law.Recycle the metal parts of the radiator by taking it to the proper recycling area.

: RAVAKANTICALC CONDITIONER - is a preparation

which perfectly renews and maintains all the qualities of the RAVAK ANTICALC protective coating; RAVAK CLEANER - works

to remove old and dried-on debris from glass surfaces, shower frames, enamel and acrylic bathtubs, washbasins and water

taps; RAVAK DESINFECTANT - is a special preparation with considerable anti-bacterial and anti-fungal effects.

IMPORTANT!

ASSEMBLYINSTRUCTIONS

PDOP1 + PPS

PDOP2 + PPS

PDOP1 + PPS

PDOP2

+ PPS

0. Content of the mounting package.

1. Turning pivot shower door one-part, two-part can be combined with one or two

fixed walls of a corresponding width.

2. Level the fixing profile into a perpendicular line using a water level. Mark the

location of the profiles clearly on the wall.

3. Encircle the holes for mounting.

4. Bore a hole and hammer in a wall plug 8 mm diameter. Beware of the electric

lines, water and gas pipes under the plaster.

5. Screw on the fixing profiles on the wall using screws 4/40 mm.

6. Slide the shower door into the profile, which is already mounted.

7. Slide the fixed wall into the profile, which is already mounted.

8. Position the corners of the products in a way, so that they could click into place.

9. Click with force.

10. Apply a silicone sealant on the seating area of the shower body and the shower

tray. Always fill the gap between the product and the shower tray only from the

outside, fill the vertical gap by the wall in the same way. The areas prepared for

filling must be dry, firm and clean.

11. The handle is adjustable.

12. If necessary, it is possible to readjust the turning pivot shower door.

13. View of the assembled product.

14. A,B... Gg
