Through beamDetection type
Model
NPN cable
NPN connector
PNP connector
PNP cable
Sensing distance 0
...
20m 0
...
10m
≥φ10mm opaque object(within Sn range)
Press the button for 2
...
5s, when the yellow and green light flash synchronously at 4Hz, and lift to finish the distance setting.
If the yellow and green light flash asynchronously @8Hz for 3s, setting fails and the product distance goes to the maximum.
/
Infrared(850nm) Red light(630nm) Red light(640nm)Red light(640nm)
Red light(640nm)
Infrared(860nm) Infrared(860nm)
/
/ /
/
0
...
100cm
0
...
30cm 0
...
10cm
8mm@30cm
3
...
20
0
...
3m*
Direction angle
Spot diameter
Sensing object
Hysteresis range
Light source
Emitter PSE-TM20D Receiver PSE-TM20DNB
Emitter PSE-TM20D-E3 Receiver PSE-TM20DNB-E3
Emitter PSE-TM20D Receiver PSE-TM20DPB
Emitter PSE-TM20D-E3 Receiver PSE-TM20DPB-E3
Emitter PSE-TM10DR Receiver PSE-TM10DNBR
Emitter PSE-TM10DR-E3 Receiver PSE-TM10DNBR-E3
Emitter PSE-TM10DR Receiver PSE-TM10DPBR
Emitter PSE-TM10DR-E3 Receiver PSE-TM10DPBR-E3
Diffuse reflection Wide-angle
PSE-BC100DNB
PSE-BC100DNB-E3
PSE-BC100DPB
PSE-BC100DPB-E3
PSE-BC30DNBR
PSE-BC30DNBR-E3
PSE-BC30DPBR
PSE-BC30DPBR-E3
PSE-BC10DNB
PSE-BC10DNB-E3
PSE-BC10DPB
PSE-BC10DPB-E3
Polarized reflection
PSE-PM3DNBR
PSE-PM3DNBR-E3
PSE-PM3DPBR
PSE-PM3DPBR-E3
Accessory Dimensions Sold Separately
Technical specifications
Dimensions
PSE
series
Through Beam
Diffuse Reflection, Wide-angle
Polarized Reflection
Through Beam
Diffuse Reflection, Wide-angle
Polarized Reflection
Optical
axis
Receiver
Emitter
Optical
axis
Receiver
Emitter
Reflector:OR12(accessory
Reflector:OR13
Reflector:OR15
Narrow Slit:FJP-01
Narrow Slit:FJP-02
Reflector:OR14
Reflector:OR10
Mounting Bracket:
ZJP-8(accessory
Model
FJP-01A
FJP-01B
FJP-01C
A Size
φ0.5mm
φ1.0mm
φ2.0mm
Material
Stainless
steel
(SUS304)
Model
FJP-02A
FJP-02B
FJP-02C
A Size
0.5mm
1.0mm
2.0mm
Material
Stainless
steel
(SUS304)
M8 Connector:CS S48L-3-2
M8 Connector:CS S49L-3-2
Terminal Wiring Diagram
Through Beam-Emitter
Diffuse Reflection,Wide-angle
Polarized Reflection, Through Beam-Receiver
BN
+
BU
-
BN
+
BU
-
BK
OUT
1
+
3
-
1
+
3
-
4
OUT
Photoelectric sensor
Operation manual
Precautions
Safety Warning
Scrap Treatment
The maximum allowable voltage of the sensor is 10% of the rated voltage,
Please confirm that the supply voltage is less than the maximum
allowable value before powering on
Do not use in an environment with flammable, explosive or corrosive gases
Do not use in oil or chemical environments
Do not use in a high humidity environment
Do not use in direct sunlight
Do not use in other environmental conditions that exceed the rated value
Do not disassemble, repair or modify this product without authorization
When the product is scrapped, please dispose of it as industrial waste
The time from powering-on to normal detection of the sensor is 100ms,
please ensure that the sensor is used after 100ms of powering-on
When using different power sources for the sensor and load, be sure to
turn on the power of the sensor first
When the sensor is not used, it is recommended to cut off the power of
the load first and then turn off the power of the sensor
When installing the sensor, do not subject the sensor to severe external
force (such as hammering, etc.), which may damage the sensor performance
Avoid using thinner, alcohol or other organic solvents when cleaning
Wiring diagram
10...30V
BN
BK
BU
Output
+
-
4
3
1
Load
Output indication
(Yellow)
Stability indication
(Green)
Photoelectric
sensor main
circuit
1
3
BN
BU
Power indication
(Green)
Power indication
(Green)
10...30V
+
-
Photoelectric
sensor main
circuit
10...30V
1
4
3
BN
BK
BU
Load
Output indication
(Yellow)
Stability indication
(Green)
Photoelectric
sensor main
circuit
Output
+
-
Through Beam-receiver, Diffuse Reflection,
Polarized Reflection, Wide-angle-NPN Output
Through Beam-Emitter
Through Beam-receiver, Diffuse Reflection,
Polarized Reflection, Wide-angle-PNP Output
Emitter
20mA
Receviver
20mA
Power, stable signal(unstable signal flash)Green
Yellow Output, overload or short circuit(flash)
≤25mA
≤200mA
≤1V
≤0.5ms≤1ms
10
...
30 VDC
Anti-ambient light interference≤10,000lux; Anti-incandescent light interference≤3,000lux
-25℃
...
55℃
-25℃
...
70℃
IP67
CE
Housing material: ABS
Filter: PMMA
EN60947-5-2:2012
IEC60947-5-2:2012
Cable:about 50g
Connector:about 10g
Operation manual,screw,reflector OR12(only for polarized reflection sensor)
Mounting bracket ZJP-8
Short circuit, Reverse polarity, Overload, Zener protection
Press the button for 5
...
8s, when the yellow and green light flash synchronously at 2Hz,and lift to finish the state switching.
Distance adjustment
Supply voltage
Consumption current
Load current
Voltage drop
NO/NC adjustment
Circuit protection
Indicator
Response time
Anti-ambient light
Ambient temperature
Protection degree
Storage temperature
Certification
Production standards
Material
Weight
Accessories
*The data is the result of the PSE polarized reflection sensor with standard reflector OR12.
Mounting
Mounting bracket
(accessory
ZJP-8
Maximum torque:
0.5N•m
Screw
Button instruction
1.Press the button for the duration time "t", if t<2s or t≥8s, the
setting is invalid, NO/NC maintains in the original state, and the
product distance maintains the original;
2.Put the product in face to the sensing object, and press the button
for the duration "t", if 2s ≤ t < 5s, the yellow and green lights
flash synchronously at 4 Hz, when the button is released to finish
distance setting.
as shown in the following figure
Note: For distancing setting, if the distance between the sensing object
and the sensor exceeds the detection ability of the product, in
duration 2s ≤ t < 5s, the yellow and green lights flash synchronously
at 4Hz, when the button is released to finish the distance setting but
not successfully.
If the yellow and green lights flash asynchronously at 8 Hz, meaning
that the product distance setting fails, and the product distance is
automatically set to the maximum value, as shown in the following
figure:
3.Press the button for the duration
"t", if 5s≤t<8s, the yellow and
green lights flash synchronously
at 2 Hz, when the button is
released to finish NO/NC state
switchover .
Flash synchronously at 4Hz
t=2
...
5s
t=2
...
5s
GREEN
Flash asynchronously at 8Hz
YELLOWGREEN
t=5
...
8s
Flash synchronously at 2Hz
YELLOWGREEN
YELLOWGREEN
Action indicator
(yellow)
Stable indicator
(green)
Action indicator
(yellow)
Stable indicator
(green)
PVC cable: φ3.9 4 pins
Standard length 2m
Minimum bending radium: 12mm
Through Beam, Diffuse Reflection,Polarized Reflection, Wide-angle Through Beam, Diffuse Reflection,Polarized Reflection, Wide-angle
0
...
5m
±2°
Emitter PSE-TM5DR
Emitter PSE-TM5DR-E3
Emitter PSE-TM5DR
Emitter PSE-TM5DR-E3
Receiver PSE-TM5DPBR
Receiver PSE-TM5DNBR
Receiver PSE-TM5DNBR-E3
Receiver PSE-TM5DPBR-E3
