Attention!
Before using the appliance please read the contents of this instruction.
Attention!
Children of 8 years old and upward intend this appliance for use and persons with reduced physical,
sensory or mental capabilities, or lack of knowledge, unless a person responsible for their safety has
given them supervision or instruction concerning the use of the appliance. Children should be supervised
to ensure that they do not play with the appliance. Cleaning and service of the device shouldn’t to be
made by children without supervision.
Safety requirements
Base on type of protection from electric shock the fans relate to the devices of class ll (220-240V/50Hz).
The climate category «moderately cold» Type «4» (УХЛ4). The level of protection against solid objects
and water:
Attention!
Specialists, who have a special allowance for such types of work, shall do connection of the fans to power
supply. The temperature of fan exploitation cannot exceed the indicated range (from +1C to +40C).
Avoid the installation of the fan to one ventilation main line with smoke-deflecting pipe from devices, having
fuel burners. In case of maintenance diagnostics, turn o the automatic breaker (S1 in OFF position) and call
an electrician.
Attention!
All actions for connection, set up, maintenance and repair of the product have to be carried out only at mains
voltage removed (S1 in OFF position).
Attention!
One-phase main, to which the fan is connected, must correspond to the norms in force. Stationary electric
wiring must be equipped with an automatic circuit breaker (S1 in the scheme). The connection is carried out
through the switch (S2 in the diagram) that is built into the stationary wiring. The gap between switch contacts
at all poles must be not less than 3 mm. In the option «-02» the switch (S3 on the scheme) is built in the fan. Before installation,
it is necessary to make sure that there is no visible damage of impeller, case, grill, and the flow passage of the case has no
any extraneous things, which may damage impeller blades.
Сorrect use
Axial duct domestic electric fan, axial duct domestic removable electric fan is designed to remove odors and excess moisture
from toilets, bathrooms and other small rooms, required ventilation.
Моdel
AURA / SILENT PARUS /RIO /PRO /STANDARD SLIM
Options
C, MT, MR,
TURBO,
No options
MRH, C
MRH
С, MR,
No options
-02, С-02, MR-
02, С MR-02,
MRH,
C MRH, MRH-
02, C MRH-02
IP 25 24 24 25 24
Symbol legend of options
Legend Name
С
Axial duct domestic removable electric fans with back flow valve.
-02
Axial duct domestic removable electric fans with the pull-chain switch of turning on/o of the power supply
or timer.
TURBO Domestic axial duct fan equipped with high capacity motor.
ET
Axial duct domestic removable electric fans with electronic timer.
HT Axial duct domestic removable electric fans with humidity sensor.
ETF
Axial duct domestic removable electric fans with phototimer.
MT Domestic axial duct fans with motion sensor
MR
Electric axial duct domestic removable multioptional fans with 2 modes and built in Fusion Logic
1.0.controller.
MRH
Electric axial channel household attachable multioption dual-mode fan with built-in Fusion Logic 1.1
controller.
EC Domestic axial duct fans with electric switch engine
Name of color
Domestic axial duct fan designed in Ivory, Champagne, Gray metal, White carbon, Black carbon, Dark gray
metal, Chrome, Gold, Matt black, Obsidian colours
Additional options can be combined or absent.
Main technical characteristics
Characteristics
AURA 4
AURA 5
PARUS 4
PARUS 5
PARUS 4
TURBO
PARUS 5
TURBO
PARUS 4 EC
PARUS 5 EC
PRO 4
PRO 5
PRO 6
RIO 4
RIO 5
SILENT 4
SILENT 5
SILENT 4
TURBO
SILENT 5
TURBO
SLIM 4
SLIM 5
SLIM 6
STANDARD 4
STANDARD 5
Flange
diameter (mm)
100 125 98 123 98 123 98 123 100 125 160 98 123 100 125 100 125 100 125 150 100 125
Eciency
(m
3
/h)
90 180 90 165 110 205 75 135 115 195 320 100 180 90 180 120 225 90 140 250 100 185
Power
consumption
(W)
8,4 10 9 13 16 20 0,05 0,07 14 18 22 14 16 8,4 10 19 20 7,8 10 10 16 20
Noise level (dB) 25 30 25 30 36 39 25 27 32 34 36 32 33 25 30 36 38 25 30 33 35 36
Weight (kg)
0,5 0,7 0,53 0,7 0,53 0,7 0,6 0,75 0,55 0,65 0,95 0,5 0,65 0,5 0,7 0,5 0,7 0,55 0,65 0,77 0,7 0,75
The fans are designed for connection to AC mains voltage 220-240 V, frequency 50 Hz.
