Constant Current Discharge Characteristics : A(25 )℃
Constant Power Discharge Characteristics : W/Cell(25 )℃
Dimensions
Specification
EV12-33H(12V33Ah)
Cells Per Unit
6
Voltage Per Unit
12V
Capacity
33Ah@20hour-rate to 1.75V per cell @25℃
Weight
Approx. 10.0 Kg (Tolerance±5%)
Max. Discharge Current
330A (5 sec)
Internal Resistance
≤10.0 mΩ (Full Charge Condition @25℃)
Terminal
Default F11(M6), F7(M8) Optional
Maxi. Charging Current
9.9A
Container Material
A.B.S. UL94-HB, UL94-V0 Optional.
Operating Temperature Range
Discharge: -20℃~60℃
Charge: 0 ~50℃ ℃
Storage: -20 ~60℃ ℃
Normal Operating Temperature Range
25 ±5℃ ℃
Float Charging Voltage
13.6 V~13.8 V @ 25℃
14.6 V~14.8 V @ 25℃
Cycle Use Voltage
Self Discharge
RITAR Valve Regulated Lead Acid (VRLA) batteries can
be stored for up to 6 months at 25℃ and then recharging
is recommended. Monthly Self-discharge ratio is less
than 3% at 25℃.Please charged batteries before using.
Reference Capacity
Cold Cranking Ampere(CCA)
230A
Temperature Compensation: -3mV/℃/Cell
Temperature Compensation: -4mV/℃/Cell
(Note) The above characteristics data are average values obtained within three charge/discharge cycle not the minimum values.
The battery must be fully charged before the capacity test. The C20 should reach 95% after the first cycle and 100% after the third cycle.
EV ( Electric Vehicle ) series is specially
designed for frequent discharge deep cycle
application. By using the specially designed
active material, strong grids and thick plate
construction, the EV series battery offers
reliable performance in high load situations
an d co ul d pr ov id e co mp et it iv e cy cl e
performance. Electric
Vehicle and Golf cart, Floor Machines,
Forklifts, Aerial lifts, Robotics, Marine, RV,
Mobility and Medical Equipment, and most
outdoor application.
It is suitable for
C3 24.8Ah
C20 33.0Ah
C5 28.1Ah
C10 31.4Ah
ISO 90 01 ISO 14 001 ISO 45 001
MH 28539
BSTXD210316008503EC
Length
Width
Height
Total Height
195±2mm (7.68 inches)
130±2mm (5.12 inches)
155±2mm (6.10 inches)
168±2mm (6.61 inches)
Terminal
M5
M6
M8
Value
6~7 N*m
8~10 N*m
10~12 N*m
Unit: mm
5
F11 TERMINAL
195 130
155
163
168
28
160
M6
Φ14
F.V/Time 5MIN 10MIN 15MIN 30MIN 1HR 2HR 3HR 4HR 5HR 8HR 10HR 20HR
1.60V 113.8 85.4 63.6 37.0 20.2 12.0 9.31 7.31 6.22 4.09 3.31 1.72
1.65V 109.7 80.7 60.9 35.6 19.5 11.6 9.02 7.12 6.06 4.05 3.27 1.69
1.70V 104.3 74.3 57.0 34.0 18.8 11.2 8.77 6.92 5.91 3.98 3.22 1.67
1.75V 97.5 68.0 53.0 32.5 18.1 10.8 8.51 6.75 5.76 3.93 3.18 1.65
1.80V 88.8 61.6 49.0 31.1 17.5 10.4 8.25 6.55 5.61 3.86 3.14 1.63
1.85V 78.1 50.3 40.6 26.7 15.7 9.54 7.63 6.09 5.23 3.62 2.95 1.55
F.V/Time 5MIN 10MIN 15MIN 30MIN 1HR 2HR 3HR 4HR 5HR 8HR 10HR 20HR
1.60V 195.8 145.2 111.3 67.3 37.9 22.7 17.8 14.0 12.0 7.99 6.50 3.38
1.65V 193.8 139.9 108.0 65.3 36.8 22.0 17.3 13.7 11.7 7.92 6.43 3.33
1.70V 186.4 131.1 102.6 63.0 35.8 21.4 16.9 13.4 11.5 7.81 6.34 3.30
1.75V 177.2 122.2 96.9 60.9 34.7 20.8 16.5 13.1 11.2 7.72 6.27 3.26
1.80V 164.3 112.6 90.7 58.7 33.6 20.1 16.0 12.8 11.0 7.61 6.19 3.23
1.85V 147.2 93.6 76.4 51.1 30.3 18.6 14.9 11.9 10.3 7.16 5.84 3.07
