Ritar EV6-310 Описание акб EV6-310 онлайн

Ritar EV6-310 Описание акб EV6-310 онлайн
Constant Current Discharge Characteristics : A(25 )℃
Constant Power Discharge Characteristics : W/Cell(25 )℃
Dimensions
Specification
EV6-310(6V310Ah)
Cells Per Unit
3
Voltage Per Unit
6V
Capacity
310Ah@20hour-rate to 1.75V per cell @25℃
Weight
Approx. 44.5 Kg (Tolerance±5%)
Max. Discharge Current
3100A (5 sec)
Internal Resistance
≤2.0 mΩ (Full Charge Condition @25℃)
Terminal
Default F22(M8), F14(M8) Optional
Maxi. Charging Current
93.0A
Container Material
A.B.S. UL94-HB, UL94-V0 Optional.
Operating Temperature Range
Discharge: -20℃~60℃
Charge: 0 ~50℃ ℃
Storage: -20 ~60℃ ℃
Normal Operating Temperature Range
25 ±5℃ ℃
Float Charging Voltage
6.80 V~6.90 V @ 25℃
7.30 V~7.40 V @ 25℃
Cycle Use Voltage
Self Discharge
RITAR Valve Regulated Lead Acid (VRLA) batteries can
be stored for up to 6 months at 25℃ and then recharging
is recommended. Monthly Self-discharge ratio is less
than 3% at 25℃.Please charged batteries before using.
Reference Capacity
Cold Cranking Ampere(CCA)
930A
Temperature Compensation: -3mV/℃/Cell
Temperature Compensation: -4mV/℃/Cell
(Note) The above characteristics data are average values obtained within three charge/discharge cycle not the minimum values.
The battery must be fully charged before the capacity test. The C20 should reach 95% after the first cycle and 100% after the third cycle.
EV ( Electric Vehicle ) series is specially
designed for frequent discharge deep cycle
application. By using the specially designed
active material, strong grids and thick plate
construction, the EV series battery offers
reliable performance in high load situations
an d co ul d pr ov id e co mp et it iv e cy cl e
performance. Electric
Vehicle and Golf cart, Floor Machines,
Forklifts, Aerial lifts, Robotics, Marine, RV,
Mobility and Medical Equipment, and most
outdoor application.
It is suitable for
C3 .5Ah 232
C20 0.0Ah 31
C5 .5Ah 263
C10 .0Ah 295
ISO 90 01 I SO 14001 ISO 45 001
MH 28539
BSTXD210316008503EC
If F22 terminal is selected and the discharge current is more than 0.25C, the threaded terminal of terminal F22 shall not be used in connection, but the lead pole shall be connected.
Length
Width
Height
Total Height
295±2mm (11.6 inches)
178±2mm (7.01 inches)
346±2mm (13.6 inches)
364±2mm (14.3 inches)
Terminal
M5
M6
M8
Value
6~7 N*m
8~10 N*m
10~12 N*m
Unit mm
:
5
F14 TERMINAL
M8
Φ18
negative
positive
18.5
17.5
M8
Φ17. 9
0
-0.3
Φ18
0
-1
17.5
M8
Φ19. 5
0
-0.3
Φ18
0
-1
295
178
101
346
364
208.8
F22 TERMINAL
If F22 terminal is selected , terminal torque :AP is 5.6 7.9 N m / M8 Stud is 6.6 8.5N m~ * ~ *
F.V/Time 30MIN 1HR 2HR 3HR 4HR 5HR 8HR 10HR 20HR
1.60V 329.0 189.4 112.3 87.4 68.7 58.5 38.4 31.1 16.1
1.65V 315.8 182.9 108.7 84.7 66.8 57.0 38.0 30.7 15.9
1.70V 301.9 177.0 105.2 82.4 65.0 55.5 37.4 30.2 15.7
1.75V 288.5 170.5 101.5 80.0 63.4 54.1 36.9 29.8 15.5
1.80V 275.8 164.0 97.9 77.5 61.5 52.7 36.3 29.5 15.3
1.85V 237.5 147.1 89.7 71.6 57.2 49.1 34.1 27.7 14.6
F.V/Time 30MIN 1HR 2HR 3HR 4HR 5HR 8HR 10HR 20HR
1.60V 597.5 355.9 212.9 167.0 131.9 112.7 75.1 61.1 31.8
1.65V 579.6 345.7 207.1 162.5 128.8 110.2 74.4 60.4 31.3
1.70V 559.6 336.5 201.4 158.8 125.8 107.7 73.4 59.6 31.0
1.75V 540.3 326.2 195.3 154.7 123.0 105.4 72.5 58.9 30.6
1.80V 521.7 315.6 189.2 150.5 119.9 103.0 71.4 58.2 30.4
1.85V 453.8 284.8 174.3 139.8 111.9 96.4 67.2 54.9 28.9
