CONTRACOR

Portable Suction Blast Tool SFG-Type Art. 10115000

6.2 Media/Air Mixture

Observe media ow through the clear media hose. Media should ow smoothly and evenly

through the hose. If the air exiting the nozzle pulses or if media does not ow smoothly, the

metering valve requires adjusting. To adjust loosen the locking nut, and adjust the metering

screw until the upper holes in the metering stem are closed-off, and the lower holes are fully

open.

If pulsation occurs in the media hose, either media is damp and caked, or not enough air

is entering the media stream. While blasting, loosen the locking nut and slowly turn the

adjusting screw out (counter clockwise when viewed from the top) until the media ows

smoothly. Tighten the locking nut to maintain the setting. If media ow is too light, decrease

air in the mixture by turning the metering screw in (clockwise when viewed from the top)

covering more of the holes so less air enters the media hose. Tighten the locking nut to

maintain the setting.

Fig. 6.2

holes fully open

Adjusting Screw

holes fully closed
