III. TECHNICAL PARAMETERS

Parameter Value

Paint funnel capacity 4.7 l

Recommended working pressure 3.5–4.8 bars

Paint funnel dimensions 230 x 255 mm

Nozzle diameters 4.5 mm, 6 mm, 8 mm

Funnel mount diameter 42 mm

Funnel lling hole diameter 200 x 105 mm

Weight 1.1 kg

IV. SPRAY GUN ITEMS

1 Ring

2 Air nozzle

3 O-ring 12.5 x 1.5

4 Sealing screw

5 Trigger lock

6 Air valve

7 Spring

8 Seal

9 O-ring 14 x 2.4

10 Sealing screw

11 Adjustment screw

12 Shaft

13 O-ring 14 x 1.9

14 O-ring 14 x 1.9

15 Nozzle

16 Cotter pin Ø4

17 Trigger

18 Pin

19 Paint funnel

20 Clamp ring

21 O-ring 41 x 3.2

22 Body

23 Quick coupler tip ¼”
