Mirka Code Item Description Kit QTY Part No

8992310111

1

Motor Housing

1

AP001

8992330002

2

Set Screw

1

AP002

8992330251

3

Oiler

1

AOS025

8992310411

4

Shield

1

AP004

5

Ball Bearing

A

1

AOS023

8992310611

6

Rear End Plate

1

AP006

8992330151

7

Spring Pin

2

AOS015

8992310811

8

Rotor

1

AP008

9

Vanes

A

4

AOS021

8992330131

10

Spacer

1

AOS013

8992330201

11

Cylinder

1

AOS020

8992311211

12

Front End Plate

1

AP012

13

O-Ring

A,D

1,1

AOS008

14

Bearing

A

1

AOS017

8992311511

15

Spacer

1

AP015

8992330271

16

Ball Bearing

1

AOS027

8992311711

17

Ball Bearing

1

AP017

18

Needle Roller

E

2

AP018

19

Needle Bearing

E

2

AP019

20

Planet Gear

E

2

AP020

8992312111

21

Planetary Carrier

1

AP021

8992330022

22

Ring Gear

1

AP022

8992312311

23

Adapter(1/4”-20)

1

AP023

8992312411

24

Rear Exhaust Cover

1

AP024

8992330341

25

Lock Nut

1

AOS034

8992312611

26

Gasket

1

AP026

8992312711

27

Air Guide

1

AP027

8992312811

28

Gasket

1

AP028

8992330011

29

Throttle Handle

1

AOS001

30

Throttle Lever

F

1

AP030

31

Spring Pin

F

1

AOS045

8992313211

32

Grip (Mirka)

1

AP032

33

Muffler Felt

D

1

AP033

8992330101

34

Muffler Plate

1

AOS010

8992331111

35

Air Inlet Bushing

1

AOS011

8992330021

36

Throttle Valve

1

AOS002

37

O-Ring

B

2

AOS007

38

O-Ring

B

1

AOS004

8992330031

39

Valve Stem

1

AOS003

40

Valve Spring

B

1

AOS005

8992330061

41

Air Regulator

1

AOS006

42

Sanp Ring

1

AOS039

43

Set Screw

C

1

MPA0131

44

Adapter(1/4”-20)

C

1

AP044

8294595311

45

Backing Pad Quick Lock 32mm Psa Hard, 10/Pack

OPT.

8294596311

45

Backing Pad Quick Lock 32mm Psa Soft, 10/Pack

OPT.

8294598311

45

Backing Pad Quick Lock 32mm Grip Soft, 10/Pack

OPT.

8294791311

46

Backing Pad 77mm 1/4" Grip Medium

1

8992314711

47

Wrench 14mm

1

AP047

48

L Shape Hex Wrench(3.0mm)

C

1

AP048

AP 300NV 77 mm Spare Parts

Page 3
