English

1. Technical Data (see Fig 2.)

RC6605RE & RC6610

Pneumatic Oscillating knife

max pressure 6.3 bar (90 psi)

:Vibration level, k Uncertainty ; L

Sound pressure level dB(A), K

= K

= 3 dB Uncertainty.

Declaration of noise (ISO 15744) and vibration emission (ISO 20643)

All values are current as of the date of this publication. For the latest information please visit www.rodcraft.com.

These declared noise values were obtained by laboratory type testing in accordance with the stated standards and are suitable for comparison with the

declared values of other tools tested in accordance with the same standards. These declared values are not adequate for use in risk assessments and values

measured in individual work places may be higher. The actual exposure values and risk of harm experienced by an individual user are unique and depend

upon the way the user works, the workpiece and the workstation design, as well upon the exposure time and the physical condition of the user.

We, RODCRAFT PNEUMATIC TOOLS , cannot be held liable for the consequences of using the declared values, instead of values reecting the actual

exposure, in an individual risk assessment in a work place situation over which we have no control.

This tool may cause hand-arm vibration syndrome if its use is not adequately managed. An EU guide to managing hand-arm vibration can be found at www.

pneurop.eu/uploads/documents/pdf/PN3-02-NV_Declaration_info_sheet_0111.pdf

We recommend a programme of health surveillance to detect early symptoms which may relate to noise or vibration exposure, so that management proce-

dures can be modied to help prevent future impairment.

Additional vibration information :

Vibration measurements have been done on real application on windscreen but the values highly depend on the conguration of the windscreen. We recom-

mend to evaluate the real working value according to standards ISO5349.

2. Machine Type

• This product is designed for cutting sheet, metal and plastic. No other use permitted. For professional use only.

• Please read the product safety information carefully!

3. Implementation and Operation

• Connect device as shown in Fig.01.

• Fix the accessories properly to the tool.

• To start the machine, simply pull the trigger (A). Machine speed is increase by increasing pressure on the trigger. Release the trigger to stop.

4. Lubrication

•

Motor Lubrication

Use an air line lubricator with SAE #10 oil, adjusted to two (2) drops per minute. If an air line lubricator cannot be used, add air motor oil to the inlet once a day.

5. Maintenance

• Follow local country environmental regulations for safe handling and disposal of all components

• Disassemble and inspect the tool every three 3 months if the tool is used every day. Replace damaged or worn parts.

• Always ensure that the machine is disconnected from energy source (compressed air) to avoid accidental operation.

• High wear parts are underlined in the parts list.

• To keep downtime to a minimum, the following service kits are recommended:

Tune-Up Kit: see part list

6. Disposal

• The disposal of this equipment must follow the legislation of the respective country.

• All damaged, badly worn or improperly functioning devices MUST BE TAKEN OUT OF OPERATION.

• Repair only by technical maintenance staff.

7. EU Declaration of conformity

We : Rodcraft Customer Center Langemarckstr.35 bis 45141 Essen- Germany

Declare that the product(s): Pneumatic Oscillating knife

Machine type(s) : RC6605RE & RC6610 Serial Number: 001 - 999

Origin of the product : Taiwan

is in conformity with the requirements of the council Directives on the approximation of the laws of the Member States relating : to “Machinery“ 2006/42/EC

(17/05/2006)

applicable harmonised standard(s) : EN ISO 11148-12 : 2012

Name and position of issuer : Pascal Roussy (R&D Manager)

Place & Date : Saint-Herblain, 01/2017

Technical le available from EU headquarter. Pascal Roussy R&D Manager LLC CP Technocenter 38, rue Bobby Sands - BP10273 44800 Saint Herblain -

France

Use only authorized parts. Any damage or malfunction caused by the use of unauthorized parts is not covered by Warranty or Product Liability.

Original instructions

Model

Stroke per min. Inner Horse Dia Net Weight Air Inlet

SoundPressure

SoundPower

Vibrations

ahd k

1 2 4 5 6 7 8

[mm] [mm] [kg]

[inch] [dB(A)] [dB(A)] [m/s²] [m/s²]
