16
NO.
Description
Qty
NO.
Description
Qty
1
Grease cup
6
37
Bolt M4×14
4
2
Bearing
2
38
Chassis
1
3
Piston rod
2
39
Washer 6
2
4
Retaining ring φ60
2
40
Bolt M6×10
2
5
Cylinder cover
2
41
Frame of travel switch
1
6
Dust cover 48×40×6.5
2
42
Travel switch
1
7
Snap ring φ65
2
43
Bolt M5×10
4
8
Guide-ring δ2×20
2
44
Bolt
6
9
Snap ring φ40
2
45
Bushing
8
10
Piston
2
46
Bushing
8
11
Composite packing
2
47
Inside scissor assembling(lower)
1
12
Cylinder welding
2
48
Washer 14
10
13
Pin for cylinder
2
49
Self-locking nut M14
8
14
Hexagon head bolt
M8×12
2
50
Outside scissor
assembling(lower)
1
15
Spring washer 8
26
51
Roller
4
16
Prevent burst valve
2
52
Prop
2
17
Spring
2
53
Bushing
2
18
Composite packing
washer 18
2
54
Bolt
2
19
Union joint
2
55
Bolt
2
20
Composite packing
washer 14
10
56
Axle bearing
8
21
High pressure hose Ⅰ
2
57
Axle bearing
8
22
Joint
5
58
Long pin
2
23
Three-way joint
1
59
Hexagon head bolt M8×20
20
24
High pressure hose Ⅱ
1
60
Short pin
4
25
Hydraulic power pack
1
61
Washer
6
26
Bolt M6×12
1
62
Pin for piston rod
2
27
Spring washer 6
1
63
Inside scissor assembling
(upper)
1
28
Washer 6
1
64
Outside scissor assembling
(upper)
1
29
Connector lug φ6-4
1
65
Safety frame
1
30
Indicator φ6
1
66
Table
1
31
Pump pack base
1
67
Spring
4
32
Spring washer 10
2
68
Buffer-board
4
33
Hex socket screw bolt
M10×20
2
69
Self-locking nut M8
4
34
Bolt M8×10
4
70
Nut M4
2
35
Control switch
1
71
Safety switch
2
36
Electric box
1
72
Fixed-board
2
73
Lifting bolt M10
4
