20

Руководство по эксплуатации

13.1.2. КАТАЛОГ ЗАПАСНЫХ ЧАСТЕЙ ДВИГАТЕЛЯ

Parts

No.

Description Q’ty

1-1

Inner six angle cylinder head combined

screwM5×20

13

1-2 Starter 1

1-3 Starter Aluminum Pad 1

1-4 Start Dial Disc 1

1-5 Oil SealFB12X22X7 2

1-6 Left and right crankcase 1

1-7 Deep Groove Ball Bearing6201 2

1-8 Woodru Key3X13X5 1

1-9 Crankcase Pad 1

1-10

Inner six angle cylinder head combined

screwM5×30

4

1-11 Igniter 1

1-12 Magnetic Flywheels 1

1-13 Hexagon Flange LocknutM8×1.25 1

1-14 Steel Plain Washerφ8X1.5 2

1-15 Shoe Assembly 1

1-16 Waved Elastic Gasketφ10X15X0.5 2

1-17 Clutch Bolt M8×φ10 2

1-18 Wind Deector 1

1-19 Positioning Pin φ5×10 2

1-20 Fan Cover 1

1-21

Inner six angle cylinder head combined

screwM5×14

3

1-22 Silencer Cover 1

1-23

Inner Hexagon Cylindrical-head

ScrewM5×55

2

1-24 Oil Tank Flat Gasketφ5×φ12×φ1 2

1-25 Silencer 1

1-26 Silencer Pad 2

1-27 Cylinder Block Cover Cap 1

Parts

No.

Description Q’ty

1-28 Cylinder Block Cover 2

1-29

Inner six angle cylinder head combined

screw M5×20(10.9 level)

4

1-30 Spark Plug 1

1-31 Air Filter Assembly 1

1-32 Air Filter Assembly 1

1-32-

1

Thumbscrew M5×9 1

1-32-

2

Air Filter Cover 1

1-32-

3

Air Filter Seat Platen 1

1-32-

4

Filter 1

1-32-

5

Air Filter Seat Package 1

1-33 Carbureter 1

1-34 Carbureter Pad 1

1-35 Inlet Pipe 1

1-36 Inlet Pipe Pad 1

1-37 Cylinder Block 1

1-38 Cylinder Block Gasket 2

1-39 Piston Ring 1

1-40 Piston 1

1-41 Crankcase Connecting Rod Assembly 1

1-42 Needle Roller Bearing K9×12×12 1

1-43 Piston Pin 2

1-44 Piston Pin Retainer 1

1-45 Protective frame 1

1-46 Oil Tank Assembly 1

1-47 Oil Tank Platen Sleeve 1

1-48 Oil Tank Platen 1
