477275_f 15

Safety instructions

level falls to the OFF height (02/b). The float

switch must be able to move freely on the surface

of the water.

3.4 Product overview(01)

No. Component

1 Pump outlet

2 Handle

3 Cable clamp

4 Inlet screen

5 Pump housing

6 Mains cable

7 Combination adapter

8 Notch for rope attachment

9 Connection for separate suction hose

10 Float switch (DIVE 6500/34 only)

3.5 Scope of supply

The pump is supplied ready for operation with

combination nipple, two covers for separate tap-

ping of water and operating instructions.

4 SAFETY INSTRUCTIONS

DANGER! Danger from contact with live

parts! A defect in the pump or the extension ca-

ble can result in serious injury!

■

Disconnect the connector plug from the

mains immediately.

■

Connect the device via an earth leakage cir-

cuit breaker with a rated leakage current of

<30mA.

CAUTION! Danger of injury from hot wa-

ter After extended use against the closed pres-

sure side (>10min.), the water in the pump can

become very hot and may escape uncontrolled!

■

Disconnect the pump from the mains supply

and allow the pump and water to cool down.

■

Check the water level on the suction side.

■

Check the leak-tightness of the lines.

■

Check the installation of the suction and

pressure lines.

■

Put the pump into operation again only after

all the faults have been remedied!

■

Never lift, transport or affix the pump by the

mains cable. Do not pull the mains cable in

order to pull the mains plug out of the socket.

■

Unauthorised modifications or conversions to

the pump are prohibited. Repairs may only

be carried out by our customer service.

■

Disconnect the mains plug before working on

the device. Protect the mains plug against

moisture.

■

Only use the pump and extension cable if

they are in flawless technical condition. Dam-

aged appliances must not be operated.

■

Maintain a safe distance to persons or ani-

mals or switch off the pump if animals ap-

proach.

Electrical safety

■

The pump may not be operated while people

are in the pool or pond.

■

The mains voltage at your location must cor-

respond to the information on the mains volt-

age in the Technical Data. Do not use any

other supply voltage.

■

The appliance must only be operated on

electrical equipment in accordance with DIN/

VDE 0100, parts 737, 738 and 702. A circuit

breaker of 10 A must be installed for fuse

protection.

■

Only use an extension cords which are de-

signed for outdoor use – minimum cross-sec-

tion 3 x 1.5mm

2

, quality of H07RN-F as per

DIN 57282/57245 with splash-proof plug

socket. Always fully unwind cable drums.

■

Check the condition of you extension cable

prior to every use.

5 INSTALLATION

5.1 Connecting the pressure line (01)

NOTE The combination nipple can be

trimmed to suit the selected hose connection.

Use the largest possible hose diameter.

1. Screw combination nipple (01/7) with seal

ring into pump outlet port (01/1).

2. Connect hose to combination nipple.

3. Fasten mains cable (01/ 6) to the pressure

line using cable ties.

4. Unwind the mains cable completely.

5. Insert the mains plug into the power socket.
