PREPARING TO WORK

HARNESS (3, Fig. 1)

Correct adjustment of the harness permits the

brush cutter to be properly balanced and at an

appropriate height from the ground (Fig. 8).

- Put on the single harness.

- Hook the brush cutter to the harness using the

hook (A, Fig. 8).

- Position the hook (18, Fig. 1) to obtain the best

brush cutter balance.

- Position the buckle (C) to obtain the correct

brush cutter height (Fig.9).

5. STARTING

FUELING

WARNING: Gasoline is an extremely

ﬂammable fuel. Use extreme caution when

handling gasoline or fuel mix. Do not smoke

or bring any ﬁre or ﬂame near the fuel or the

unit.

· To reduce the risk of fire and burn injury,

handle fuel with care. It is highly flammable.

· Mix and store fuel in a container approved for

gasoline.

· Mix fuel outdoors where there are no sparks or

flames.

· Select bare ground, stop engine, and allow to

cool before refueling.

· Loosen fuel cap slowly to release pressure and

to keep fuel from escaping around the cap.

· Tighten fuel cap securely after refueling. Unit

vibration can cause an improperly tightened

fuel cap to loosen or come off and spill

quantities of fuel.

· Wipe spilled fuel from the unit. Move 3 metre

away from refueling site before starting

engine.

· Never attempt to burn off spilled fuel under

any circumstances.

· Do not smoke while handling fuel or while

operating the unit.

FITTING THE DISK (Fig. 7)

Fix the blade (R) onto the upper ﬂange (F) making

sure that the rotation direction is correct.

Fix the lower ﬂange (B), the cup (D) and tighten bolt

(A) anti-clockwise.

Put the pin provided in the appropriate hole (L)

to block the blade and allow the bolt (A) to be

tightened to 2.5 kgm (25 Nm).

WARNING – Collar (see arrows C, Fig.7)

must locate in blade’s mounting hole.

FITTING THE HANDLE (Fig. 2)

Fit the handle (A) onto the shaft arm and secure it

using screws (D). The handle position is calculated

depending on the requirements of the operator.

WARNING - Assemble the loop handle (A,

Fig.2-3) between label’s arrow (B) and rear

handle (C).

FITTING THE HANDLEBAR (FIG.5B)

- Loosen the clamp screws (D).

- Insert the 2 halves of the handlebar in the

respective sockets (E).

- Retighten the screws (D)

MOUNTING THE CONTROL HANDLES (Fig. 5A)

- Loosen the screw (G). The nut (H) remains in the

control handle (L).

- Push the control handle (L) (throttle trigger M

must point toward the gearbox) onto the bike

handle (N) so that the holes (P) line up.

- Insert screw (G) and tighten down ﬁrmly.

ASSEMBLING THE BIKE HANDLE (Fig. 5C)

- Place the bike handle (A, Fig.4) in the lower hub

(B1).

- Place the upper hub (B2) in position and tighten

the 4 screws (D), without ﬁnally tighten yet.

- Line up the handlebar at a right angle to the

drive tube.

- Tighten down the screws (D) ﬁrmly.

WARNING: Make sure that all

components are connected properly and all

screws tightened.
