until fully charged. To charge the battery pack, see theHow To Charge The Battery

Packsection below.

As Required- To check available charge, push the Battery Fuel Gauge button (E,

Figure67) and charge if required. See theBattery Fuel Gaugesection.

How To Charge The Battery Pack

WARNING

Keep the battery charger dry. Avoid exposing the battery pack to rain or wet

conditions.

1. Connect the battery charger (F, Figure89) to an electrical outlet.

2. Portable Battery Pack:Slide the battery pack (G, Figure8) firmly into the battery

charging bay (F). If the red charging light does not illuminate, remove the battery

pack and reinstall. Make sure the battery pack is firmly seated in the battery

charging bay.

• Red light (A, Figure6) indicates the battery pack is charging normally.

• Green light (B) indicates the battery pack is fully charged.

• Red light (C) flashes indicates that the battery pack is either too hot or

too cold and will not accept a charge. Leave the battery pack connected

and when normal operating temperature is reached it will automatically

start charging. See theSpecificationssection for normal operating

temperature.

• Red/green lights (D) flashes indicate that the battery pack will not charge

and must be replaced.

3. Portable Battery Pack:From “sleep mode”, the battery will wake up in

approximately ten (10) seconds.

4. Portable Battery Pack:A completely discharged battery pack will fully charge in

approximately one (1) hour. The battery pack will stay fully charged if left on the

charger.

5. Portable Battery Pack:When the green light indicates that the battery pack is

fully charged, remove the battery pack from the charger.

6. Integrated Battery Pack:Connect the charger plug (G, Figure9) to the engine.

7. Integrated Battery Pack:A completely discharged battery pack will fully charge in

approximately four (4) hours.

8. Integrated Battery Pack:When the green light indicates that the battery pack is

fully charged, remove from the charger.

9. To check available charge, push the Battery Fuel Gauge button (E, Figure67).

10. When not in use, disconnect the battery charger from the electrical outlet.

Battery Fuel Gauge

To check available charge, push the Battery Fuel Gauge button (E, Figure67). The

display lights (H) will indicate the approximate amount of available charge remaining in

the battery pack.

Display Lights Available Charge

Four lights 75% to 100%

Three lights 50% to 75%

Two lights 25% to 50%

One light 10% to 25%

Light flashes Low

Integrated Battery Pack:When connected to the charger, if all display lights are off

then the battery is fully charged. Disconnect the charger.

Start and Stop Engine

See Figure:10,11,12,13

Start Engine

WARNING

Fuel and its vapors are extremely flammable and explosive.

Fire or explosion can cause severe burns or death.

When Starting Engine

• Make surethat spark plug, muffler, fuel cap and air cleaner (if equipped) are in

place and secured.

• Do not crank engine with spark plug removed.

• If engine floods, set choke (if equipped) to OPEN or RUN position, move throttle (if

equipped) to FAST position and crank until engine starts.

WARNING

Improper use of battery and charger can result in an electrical shock or fire.

When Operating

• Keep battery charger dry. Avoid exposing battery pack to rain or wet conditions.

• To reduce the risk of electrical shock, do not allow water to flow into AC plug.

• Do not short circuit; never place any object into the battery contacts.

WARNING

POISONOUS GAS HAZARD. Engine exhaust contains carbon monoxide, a

poisonous gas that could kill you in minutes. You CANNOT see it, smell it, or

taste it. Even if you do not smell exhaust fumes, you could still be exposed to

carbon monoxide gas. If you start to feel sick, dizzy, or weak while using this

product, shut it off and get to fresh air RIGHT AWAY. See a doctor. You may

have carbon monoxide poisoning.

• Operate this product ONLY outside far away from windows, doors and vents to

reduce the risk of carbon monoxide gas from accumulating and potentially being

drawn towards occupied spaces.

• Install battery-operated carbon monoxide alarms or plug-in carbon monoxide

alarms with battery back-up according to the manufacturer's instructions. Smoke

alarms cannot detect carbon monoxide gas.

• DO NOT run this product inside homes, garages, basements, crawlspaces,

sheds, or other partially-enclosed spaces even if using fans or opening doors and

windows for ventilation. Carbon monoxide can quickly build up in these spaces

and can linger for hours, even after this product has shut off.

• ALWAYS place this product downwind and point the engine exhaust away from

occupied spaces.

NOTICE This engine was shipped from Briggs & Stratton without oil. Before you

start the engine, make sure you add oil according to the instructions in this manual.

If you start the engine without oil, it will be damaged beyond repair and will not be

covered under warranty.

Note:Equipment may have remote controls. See the equipment manual for location and

operation of remote controls.

1. Check the engine oil. See theCheck Oil Levelsection.

2. Modelswithportable battery pack:Mount the battery pack (A, Figure10) in

the engine battery tray on top of the engine. Make sure battery pack is securely

installed. Battery pack may represent equipment key in some instances.

Note:Modelswithportable battery pack:To wake up a new battery, aFirst

Timequick charge of approximately ten (10) seconds is required. See theWhen To

Charge Battery Packsection.

3. Make sure equipment drive controls, if equipped, are disengaged.

4. Move the fuel shut-off (D, Figure11), if equipped, to the OPEN position.

5. Move the throttle control (B, Figure11), if equipped, to the FAST position. Operate

the engine in the FAST position.

6. Modelswithelectric start switch:Hold the engine stop lever (C, Figure12)

against the handle. Move the electric start switch to the START position. See the

equipment manual for the location and operation of the electric start switch.

7. Modelswithoutelectric start switch:Hold the engine stop lever (C, Figure12)

against the handle. Engine will automatically start. See the equipment manual for

operation of the engine stop lever.

NOTICE To extend the life of the starter, use short starting cycles (five seconds

maximum). Wait one minute between starting cycles.

Modelswithportable battery pack:If the engine will not crank and the battery pack

display lights are flashing, then the battery pack temperature is too hot or current draw is

too high. All four battery display lights (H, Figure13) will flash a warning for 10 seconds.

The battery pack does not have a fuse, but will automatically reset after 10 seconds. If

battery pack temperature is too hot (over 140 F, 60 C), remove the battery and allow it

to cool. To avoid excess current draw on lawnmowers, keep the mower housing clean of

grass build-up and debris.

Note:If the engine does not start after repeated attempts, contact a local dealer or go

toBRIGGSandSTRATTON.comor call1-800-233-3723(in USA).

Stop Engine

1. Engine Stop Lever:Release the engine stop lever (E, Figure12).

Throttle Control, if equipped with stop feature:Move the throttle control (B,

Figure11) to the STOP position.

Electric Start Switch, if equipped:Move the electric start switch to the OFF /

STOP position. See the equipment manual for the location and operation of the

switch. Remove the key and keep in a safe place out of the reach of children.
