These operating instructions describe the maximum

equipment. Depending on the model, there are differ-

ences in the scopes of delivery (see packaging).

See fold-out page 3 for illustrations

1 Quick coupling for high pressure hose

2 High pressure connection

3 Appliance switch "0/OFF“/ „I/ON“

4 Storage hook for mains connection cable

5 Storage for high pressure hose

6 Transport handle

7 Water connection with integrated sieve

8 Detergent suction hose with detergent filter and lid

9 Detergent Tank

10 Coupling element for water connection

11 Storage for spray lance

12 Storage for trigger gun

13 Mains cable with mains plug

14 Bearing wheel

15 Trigger gun

16 Lock trigger gun

17 Key to detach the high pressure hose from the trig-

ger gun

18 High pressure hose

19 Spray lance with pressure regulation (Vario Power)

Carrying out the most common cleaning tasks. The

work pressure can be stagelessly regulated be-

tween "Min" and "Max". You can add detergent

when "Mix" is selected.

In order to adjust the working pressure, release the

lever of the hand spray gun and turn the spray

lance to the desired position.

20 Spray lance with Dirtblaster

For strong contaminations

* Optional accessories

21 Washing brush

Suitable for use with detergents.

22 Rotary washing brush

Suitable for use with detergents.

Especially suitable for cleaning cars.

23 Foam nozzle with detergent container

With powerful foam for effortless cleaning.

** not included in the scope of delivery

24 Water supply hose

Use a fabric reinforced water hose with a commer-

cially available coupling. Minimum diameter 13 mm

(1/2 inch); minimum length 7.5 m.

Special accessories expand the possibilities of using

your appliance. Please contact your KÄRCHER dealer

for further information.

Mount loose parts delivered with appliance prior to start-

up.

See fold-out page 4 for illustrations

Illustration

 Push the wheels into the intake.

 Secure the wheels using the included plug. Align

the plug properly!

Illustration

 Insert the transport handle and screw in.

Illustration

 Screw the coupling element to the water connec-

tion on the appliance.

Illustration

 Fasten the quick coupling for the high pressure

hose to the high pressure connection.

Illustration

 Push the high pressure hose into the trigger gun

until it locks audibly.

Note: Make sure the connection nipple is aligned

correctly.

 Check the secure connection by pulling on the high

pressure hose.

 Park the appliance on an even surface.

Illustration

 Push the high pressure hose into the quick cou-

pling until it locks audibly.

Note: Make sure the connection nipple is aligned

correctly.

Check the secure connection by pulling on the high

pressure hose.

 Insert the mains plug into the socket.

For connection values, see type plate/technical data.

Observe regulations of water supplier.

ATTENTION

Impurities in the water can damage the high-pressure

pump and the accessories. For protection, the use of

the KÄRCHER water filter (optional accessory, order

no. 4.730-059) is recommended.

 Attach the water supply hose to the coupling on the

water connection.

 Connect the water supply hose to the water supply.

 Completely open the water tap.

Description of the Appliance

Special accessories

Assembly

Start up

Water supply from mains

11EN
