The vendor is not liable for any damage or malfunction resulting from unqualified

mounting and/or not following the mounting instructions.

Proper device mounting is required both to ensure correct device operation and to retain

eligibility for warranty services. Make sure that the mounting specialist includes all the

required information about the installation in the warranty card.

After completing the installation, remove the air filters from the protective bags and

place them in the corresponding slots in the device.

After installing the filter unit cover and decorative panel, plug the unit into the power

supply.

3 Electrical Connection

The device must be connected to a power supply before operation. This can be done using

open or concealed wiring.



power for the selected power line is at least 2 kW provided that no other device is used in

parallel on the same power line.

After being connected to the power supply, the device will go into standby mode.

4 Open Wiring

The device comes with a power cord. Connect the cable connector to the mating connector on

the back of the device. Connect the device to the electrical network.

The cable supplied with the device can be substituted with one of a different length or color

provided that it meets the following requirements:

• The plug must comply with the C4 standard



international standard CEE 7/7

• The cable outlet must comply with GOST IEC



• 



5 Concealed Wiring



structural units of the building.

CEE 7/7

C13 f

S³ 1mm2
