1 DESCRIPTION
1.1 OVERVIEW
Figure 1-22
1
Guide bar cover
2
Front handle
guard / chain brake
3
Front handle
4
Lock out button
5
Trigger
6
Oil tank cap
7
Oil indicator
8
Spike bumpers
9
Saw chain
10
Guide bar
11
Wrench
12
Rear handle
13
Chain tension
screw
14
Chain cover
15
Chain cover nuts
16
Bolt for saw chain
tension
17
Sprocket
18
Battery release
button
19
Oil outlet
20
Bar groove
21
Chain drive links
22
Cutter
23
Felling direction
24
Danger zone
25
Escape route
26
Direction of fall
27
Notch
28
Felling back cut
29
Hinge
30
Limb cut
31
Keep work off
ground leave
support limbs until
log is cut
32
Log supported
along the entire
length
33
Cut from top (over
buck) avoid cutting
earth
34
Log supported one
end
35
Under buck
36
Over buck
37
Log supported both
ends
38
Bucking a log
39
Stand on uphill side
when cutting
because log may
roll
2 SAFETY
WARNING
Make sure that you do/obey all safety instructions.
Refer to Safety Manual.
3 INSTALLATION
WARNING
Do not change or make accessories that are not
recommended by the manufacturer.
WARNING
Do not put in the battery pack until you assemble all
the parts.
3.1 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine
before use.
WARNING
• If the parts have damage, do not use the machine.
• If you do not have all the parts, do not operate the
machine.
• If the parts are damaged or missing, speak to the
service center.
1. Open the package.
2. Read the documentation in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and package in compliance with
local regulations.
3.2 ASSEMBLE THE GUIDE BAR AND
THE CHAIN
Figure 1-7.
1. Remove the chain cover nuts with the wrench.
2. Remove the chain cover.
3. Put the chain drive links into the bar groove.
4. Put the chain cutters in the direction of the chain
operation.
5. Put the chain in position and make sure that the
loop is behind the guide bar.
6. Hold the chain and bar.
7. Put the chain loop around the sprocket.
8. Make sure the chain tension pin hole on the guide
bar fits correctly with the bolt.
9. Install the chain cover.
10. Tighten the chain. Refer to
Adjust the chain tension.
11. Tighten the nuts when the chain is well tensioned.
NOTE
If you start the chain saw with a new chain, have a test
for 2-3 minutes. A new chain gets longer after the first
use, examine the tension and tighten the chain if
necessary.
3.3 INSTALL THE BATTERY PACK
Figure 2
5
English
EN
